Specifications
Overview
IR Resolution
80 × 60 (4,800 pixels)
Sensitivity
150 mK
Size (L x W x H)
43 x 89 x 241 mm (1.7 x 3.5 x 9.5 in)
Warranty
10 year
Weight
426 g (15 oz)
Worklights
Yes
Connections & Communications
Connectivity
N/A
Environmental
Drop test
2 m
Emissivity Settings
4 Presets with Custom Adjustment
Imaging & Optical
Color palettes
Iron, Rainbow, Grayscale
Display Size
2.0 in TFT screen
Focus
Fixed
Gallery
17542
Imaging Detector
FLIR Lepton® microbolometer
Field of View [V x H]
38.6° x 50.0°
Measurement & Analysis
AC/DC Voltage
Range 1000V / Basic Accuracy ±1.0%
Capacitance
Range 1000µF / Basic Accuracy ±1.0%
Diode
Range 1.5V / Basic Accuracy ±1.5%
Inrush AC Current
Range 600.0A / Basic Accuracy ±3.0%
LoZ Mode AC Voltage
Range 1000V / Basic Accuracy ±1.0%
LoZ Mode DC Voltage
Range 1000V / Basic Accuracy ±1.0%
Resistance
Range 6000Ω / Basic Accuracy ±1.0%
Temperature Accuracy
± 3°C (5.4°F) or ±3% of rdg
Temperature Range
-13°F to 302°F (-25°C to 150°C)
VFD AC Current
Range 600.0A / Basic Accuracy ±2.0%
VFD AC Voltage
Range 1000V / Basic Accuracy ±1.0%
True RMS
Yes
Continuity check threshold
30Ω to 150Ω
Meter Data
Auto Power Off
Yes
Auto Range
Yes, with manual range option
Performance
Measuring Rate
3 samples per second
Power
Battery
4 AAA batteries; optional TA04 Li-Poly rechargeable battery
Storage Media
Data Logging & Storage
N/A
