Specifications
Overview
Compression
H.264, MPEG-4, MJPEG (dual stream)
Detection Functionalities
Vehicle and bike presence, counting, inverse direction
Dimensions (incl mounting bracket)
Vertically mounted 45cm x 16cm x 12cm (17.7 x 6.3 x 4.7 inch) Horizontally mounted 41cm x 18cm x 12cm (16.1 x 7.1 x 4.7 inch)
Material
All weatherproof (UV-resistant)
Sunshield
Optional
Type
Long wave Infrared (7 – 14 µm)
Connections & Communications
Ethernet
For communication of output state events, configuration & monitoring (streaming video)
Electrical & Mechanical
Contact Closures
3 for ETH versions, direct or via optional ETH interface (PN 10-6075) 4 for TI x-stream EDGE (PN 10-6055), 12 extra outputs via 4/Os xp expansion boards
PC Tool for Set-Up
Traficon Configuration Tool (TCT)
Environmental & Approvals
EU Directives
EMC 2004/108/EC
FCC
FCC part 15 class A
Protection Grade
Housing = IP68, Connectors = IP67
RoHS 2011-65-EU
0-95% relative
Shock & Vibration
NEMA II specs
Temperature Range
From -34°C to +80°C (-29°F to 165°F)
Imaging & Optical
Frame Rate
30 FPS
Resolution
QVGA (336 x 256)
Other
Number of Detection Zones
24 vehicle presence zones 4 bike presence regions 8 inverse direction zones
Power
Current Consumption
< 150mA @ 24VDC (< 200mA @ 24VDC peak at start-up)
Input Power
12-42VDC, 12-30VAC
Power Consumption
≤ 3,6W (≤ 4,8W peak at start-up)
