FCB-Series AI
Thermal AI Analytics Camera
The FCB-Series AI thermal security camera turns noisy, cluttered sites into clear, dependable views your team can act on. With industry-leading thermal sensitivity (<20 mK), it visualizes objects through fog, drizzle, and night-time glare, so a person slipping between stacked containers or walking along a dark campus fence line doesn’t vanish in the shadows. Onboard AI analytics distinguish people and vehicles from swaying trees or rain on the lens, cutting the nuisance alarms that currently flood your VMS. Nexus-enabled geolocation and PTZ handoff let operators click on a target and follow it around corners, along the fence, or between buildings, while flexible lens options and an IP67 housing make it easy to cover awkward yard layouts, loading bays, and remote installations.
This is a camera built for real sites, not lab conditions
Ventaja de Flir Nexus
Realice un geoseguimiento perfecto de objetivos en áreas amplias a través de Flir Nexus, un protocolo de comunicación patentado que ayuda a salvar la brecha entre la IA de la serie FCB, otras cámaras de seguridad, dispositivos de radar y sus sistemas de supervisión. Nexus permite una coordinación perfecta para mantener un seguimiento continuo, más allá del campo de visión de un solo dispositivo.
Ciberseguro y compatible con NDAA
Proteger sus datos es tan importante para nosotros como la seguridad del sitio para usted. Las cámaras de IA de la serie FCB son ideales para sistemas de seguridad ciberendurecidos para infraestructura crítica y aplicaciones gubernamentales. El desarrollo de Flir cumple con los estándares de cumplimiento de NDAA al incorporar consideraciones de ciberseguridad en nuestro proceso junto con pruebas de vulnerabilidad internas y externas, revisiones de código estrictas y rigurosos protocolos de TI.
• Fewer false alarms from waving foliage or rain.
• Security teams see alarms when someone climbs the fence, instead of wasting time clearing endless false alerts.
• Crisp thermal silhouettes visible between parked vehicles, misty yards, or across campus boundaries.
• Operators can detect and respond with confidence.
• Nexus-enabled geolocation and PTZ handoff mean an intruder spotted at a remote gate can be instantly handed over to a PTZ for close-up tracking.
• Rugged IP67 camera built to endure dust, heat, and driving rain at remote energy sites and busy industrial yards.
Especificaciones
| Analytics | |
|---|---|
| Cybersecurity | Password protection, Password policy enforcement, IP filtering, IEEE 802.1X, Digest authentication, CA & self-signed certificates, Firewall |
| Compliance & Certifications | |
|---|---|
| Compliance | CB Scheme IEC 62368-1:2018, comply with IEC62368-1:2020+A112020 |
| Environmental | |
|---|---|
| De-Icing\Defogging | •De-fog: Yes, built in heaters •De-icing: No |
| EMC | CE marked (EN 55032 & EN 55035) , EN 61000-6-3, EN 50130-4, FCC Part 15 (subpart B, class A), RoHS, WEEE, UKCA, ICES-003, AS/NSZ CISPR 32 |
| Handling Shock | ISTA 3A |
| Humidity | 0-95% relative humidity |
| IP Rating (dust & water ingress) | IP67, NEMA 4X |
| Operating Temperature Range | -40°C to 60°C/-40°F to 140°F (cold start) |
| Storage Temperature Range | -50°C to 85°C (-58°F to 185°F) |
| Vandal Resistance | Yes (except windows) |
| General | |
|---|---|
| Detector Type | Long-life, uncooled, sun-safe VOx microbolometer |
| Dimensions (L x W x H) | 378 × 96.9 × 85.4 mm (14.9 × 3.8 × 3.4 in) |
| Effective Resolution | •VGA: 327,680 pixels •QVGA: 81,920 pixels |
| Input Voltage | •PoE+ (802.3at), heater off: 6.8 W •PoE+ (802.3at), heater on (@ 100%): 13.5 W •12 VDC, heater off: 7.2 W •12 VDC, heater on (@ 100%): 12.4 W •24 VAC (VA), heater off: 7.0 W •24 VAC (VA), heater on (@ 100%): 12.5 W |
| Part Number | 427-2064-20-00 |
| Warranty | Camera: 3 years / Sensor: 10 years |
| Weight | 2.34 kg |
| Measurement & Analysis | |
|---|---|
| Analytics Features | Region entrance/Intrusion detection, Crossover/fence trespassing, CNN classifier |
| Analytics Management | Web-based configuration and management; masking of analytic detection areas, adjustable sensitivity, automatic responses, remote I/O control |
| System Integration | |
|---|---|
| Audio | 1 × Line Input, G.711 a-law/μ-law, AAC support + 1 × Line Output |
| Control Input/Output | 1 × dry contact in; 1 × relay out (rated load: 0.025 A @ 5 VDC) |
| Ethernet | 10/100/1000 IEEE 802.3, auto sensing 1 × RJ45 |
| External Analytics Compatible | Yes |
| Network APIs | NEXUS SDK, NEXUS CGI, ONVIF Profile S, G, T |
| Streaming Resolution | •VGA: 640 × 512 •QVGA: 320 × 256 |
| Supported Protocols | IPv4, HTTP, HTTPS, UPnP, DNS,NTP, RTSP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, ONVIF Profile G/T/S |
| Thermal Camera | |
|---|---|
| Array format | •VGA: 640 × 512 •QVGA: 320 × 256 |
| f-number | f/1.0 |
| Field of view (FOV) | 50° × 40° |
| Focal Length | 4.3 mm |
| Focus | Athermalized, focus-free |
| Image Uniformity Optimization | Automatic flat field correction (FFC); thermal and temporal triggers |
| Pixel Pitch | 12 μm |
| Sensitivity | •VGA: <20 mK •QVGA: <30 mK |
| Spectral Range | 8 μm to 14μm |
| Thermal AGC Region of Interest [ROI] | Default, Presets, and User definable to ensure optimal image quality on subjects of interest |
| Thermal Frame Rate | •VGA: 30 Hz •QVGA: 8.3 Hz |
| Thermal Image Settings | Brightness, Contrast, Sharpness, Auto AGC, Digital Detail Enhancement (DDE), Gamma, Smart Screen Optimization |
| Video & Recording | |
|---|---|
| IP Video | Two independent H.265/H.264/MJPEG streams |
| Local Storage | Up to 2TB SD card (sold separately) |
Accessories
Export Restrictions
The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
