New
Flir i34
App-Enabled Thermal Camera
Top application
- Asset Reliability
- Building Diagnostics & Indoor Air Quality
- Electrical Inspection
- Mechanical Inspection
The Flir i34 is the smart, scalable way to bring thermography to more people across your team—without compromising on consistency or control. With 240 × 320 thermal resolution and the power of the Flir ACE platform, the i34 transforms inspections into app-guided, repeatable workflows that anyone can follow—helping you capture the right data, in the right place, at the right time.
The i34 supports fully guided inspection routes, on-camera fault detection, baseline image comparison, and direct integration with Flir Assetlink and Ignite. Whether you're expanding your predictive maintenance program or reducing reliance on paper-based reporting, the i34 helps standardize inspections and eliminate guesswork—no matter the user’s experience level.
With a wide field of view, glove-friendly controls, and cybersecure data transfer behind your IT firewall, the i34 is your entry point to smarter, more connected thermography—designed to scale with your goals, not your workload.
With the advantage of Flir, 3rd-party, and custom apps, iXX-Series cameras simplify inspections and improve workflow for increased productivity. Apps can reduce the steps between data gathering and consumption, letting you work the way that makes the most sense for your organization.
On-board apps can flatten the learning curve, provide safety information, host training, and offer remote support so inexperienced users can perform expert-level inspections.
Flir iXX cameras can host a range of apps—Flir-made, 3rd-party, and custom—designed to address communication, documentation or decision-making needs.
Especificações
| Highlighted | |
|---|---|
| Resolução de IV | 240 × 320 |
| Sensibilidade Térmica/NETD | <40 mK at 30°C (86°F) |
| Precisão | ±2°C (±3.6°F) or ±2% |
| Campo de visão (FOV) | 38° × 49° |
| Câmera Digital | 8 MP, Autofocus |
| Modos de Imagem | MSX®, Thermal, Picture-in-Picture, Digital camera |
| Mídia de Armazenamento | Internal memory, onboard Flir Ignite cloud and Assetlink connectivity |
| Geração de imagem e óptica | |
|---|---|
| Ajuste Automático da Imagem | Yes |
| Ajuste Manual da Imagem | Yes |
| Alinhamento a Laser | Position of laser pointer automatically displayed on the infrared image |
| Campo de visão (FOV) | 38° × 49° |
| Cor | Black |
| Câmera Digital | 8 MP, Autofocus |
| Distância Focal Mínima | 0.5 m |
| Faixa Espectral | 7.5 to 13 µm |
| Foco | Fixed focus |
| FOV da Câmera Digital | 50.5° × 64.5° |
| Frequência da Imagem | 30 Hz |
| Modos de Imagem | MSX®, Thermal, Picture-in-Picture, Digital camera |
| Número f | 1.4 |
| Paletas de cores | Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC |
| Resolução de IV | 240 × 320 |
| Resolução do Display | 720 × 1280 |
| Resolução espacial (IFOV) | 2.9 mrad |
| Sensibilidade Térmica/NETD | <40 mK at 30°C (86°F) |
| Tipo de Display | 5 in. color LCD |
| Medição e análise | |
|---|---|
| Correção de Emissividade | Variable from 0.1 to 1.0 |
| Correções de Medição | Emissivity, matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation |
| Delta T | Yes, NFPA 70B compliant |
| Dimensões da câmera (C x L x A) | 225 × 136 × 73 mm (8.9 × 5.4 × 2.9 in) |
| Faixa de Temperatura de Objetos | -20°C to 200°C (-4°F to 392°F) 10°C to 450°C (50°F to 842°F) |
| Fotômetro | Center spot, box with min./max. |
| Isotérmico | Above, Below |
| Peso da câmera com bateria | 0.8 kg (1.76 lb) |
| Precisão | ±2°C (±3.6°F) or ±2% |
| Interface do usuário | |
|---|---|
| Tela Sensível ao Toque | Capacitive touch |
| Texto | Text annotation on image using onscreen keyboard |
| Comunicação e armazenamento de dados | |
|---|---|
| Formatos de Arquivo | Standard JPEG, 14-bit measurement data included |
| Interface | USB-C: Data transfer to and from PC and Mac device Display port over USB-C |
| Mídia de Armazenamento | Internal memory, onboard Flir Ignite cloud and Assetlink connectivity |
| Operação de CA | Optional accessory: 45 W AC adapter, 100 V to 240 V AC input, 15 V DC, 3 A output to camera |
| Wi-Fi | IEEE 802.11 a/ac/b/g/n (2.4 and 5 GHz) |
| Potência | |
|---|---|
| Gerenciamento de Energia | Automatic shut-down |
| Sistema de carregamento | Battery is charged inside the camera or in specific charger (included) |
| Tempo de Carregamento | 2 hours in charger / 4 hours to 90% capacity in camera |
| Tempo Operacional da Bateria | 4 hours at 25°C (77°F) ambient temperature and typical use |
| Tipo de bateria | Rechargeable Lithium-ion battery |
| Dados ambientais e certificações | |
|---|---|
| Choque | 25 g (IEC 60068-2-27) |
| Classificação do Laser | Class 2 |
| EMC | EN 301 489-1, EN 301 489-17, EN 61000-6-3, EN 61000-6-2, FCC 47 CFR Part 15 Class B |
| Encapsulamento | IP54 (IEC 60529) |
| Espectro de Rádio | ETSI EN 300 328 ETSI EN 301 893 FCC 47 CFR part 15 RSS-247 |
| Faixa de Temperatura de Armazenamento | -40°C to 70°C (-40°F to 158°F) |
| Faixa de Temperatura Operacional | -15°C to 50°C (5°F to 122°F) |
| Queda | 2 m (6ft 7 in) |
| Tabela de Emissividade | Emissivity table of predefined materials |
| Umidade | IEC 60068-2-30/24 h 95% relative humidity |
| Vibração | 2 g (IEC 60068-2-6) |
| Geral | |
|---|---|
| Lanterna | Manually activated bright LED |
| O Pacote Inclui | Infrared camera with battery Extra battery Battery charger USB-C cable Printed documentation Hard transport case Wrist strap |
