Extech 382202

18V/3A 单通道输出直流电源

Extech 382202 是一款直流电源，可提供 0 V 至 30 V 和 0 A 至 1 A 的可调输出。它采用双背光 LCD 显示屏来显示电流和电压，以及短路和过载保护情况。在 120 VAC ± 10%/60 Hz 电源下工作。香蕉插头输出。配有电源线。

规格

一般参数
Line Current Regulation <0.2% + 3mA
Line Voltage Regulation <0.01% + 3mV
Load Current Regulation <0.2% + 3mA
Load Voltage Regulation <0.01% + 2mV
Output Current 0 – 3.00A（直流）
Output Current Basic Accuracy 读数的 ±2%
Output Voltage 18.0V（直流）
Output Voltage Basic Accuracy 读数的 ±1.5%
Ripple and Noise <0.5mV/<3mA
其他详情
Dimensions 240 × 108 × 154mm
Power 115V/230V；50/60Hz
Warranty 2 年
Weight 3kg
