FCB-Series AI
Thermal AI Analytics Camera
The FCB-Series AI thermal security camera turns noisy, cluttered sites into clear, dependable views your team can act on. With industry-leading thermal sensitivity (<20 mK), it visualizes objects through fog, drizzle, and night-time glare, so a person slipping between stacked containers or walking along a dark campus fence line doesn’t vanish in the shadows. Onboard AI analytics distinguish people and vehicles from swaying trees or rain on the lens, cutting the nuisance alarms that currently flood your VMS. Nexus-enabled geolocation and PTZ handoff let operators click on a target and follow it around corners, along the fence, or between buildings, while flexible lens options and an IP67 housing make it easy to cover awkward yard layouts, loading bays, and remote installations.
This is a camera built for real sites, not lab conditions
Flir Nexus Advantage
Seamlessly geo-track targets across wide areas through Flir Nexus, a proprietary communication protocol that helps bridge the gap between the FCB-Series AI, other security cameras, radar devices, and their monitoring systems. Nexus enables seamless coordination to maintain continuous tracking—beyond a single device's field of view.
• Fewer false alarms from waving foliage or rain.
• Security teams see alarms when someone climbs the fence, instead of wasting time clearing endless false alerts.
• Crisp thermal silhouettes visible between parked vehicles, misty yards, or across campus boundaries.
• Operators can detect and respond with confidence.
• Nexus-enabled geolocation and PTZ handoff mean an intruder spotted at a remote gate can be instantly handed over to a PTZ for close-up tracking.
• Rugged IP67 camera built to endure dust, heat, and driving rain at remote energy sites and busy industrial yards.
规格
| Analytics | |
|---|---|
| Cybersecurity | Password protection, Password policy enforcement, IP filtering, IEEE 802.1X, Digest authentication, CA & self-signed certificates, Firewall |
| 合规性与认证 | |
|---|---|
| 合规性 | CB Scheme IEC 62368-1:2018, comply with IEC62368-1:2020+A112020 |
| 环境 | |
|---|---|
| De-Icing\Defogging | •De-fog: Yes, built in heaters •De-icing: No |
| IP防护等级（防尘防水） | IP67, NEMA 4X |
| 存储温度范围 | -50°C to 85°C (-58°F to 185°F) |
| 工作温度范围 | -40°C to 60°C/-40°F to 140°F (cold start) |
| 湿度 | 0-95% relative humidity |
| 电磁兼容性（EMC） | CE marked (EN 55032 & EN 55035) , EN 61000-6-3, EN 50130-4, FCC Part 15 (subpart B, class A), RoHS, WEEE, UKCA, ICES-003, AS/NSZ CISPR 32 |
| 运输振动 | ISTA 3A |
| 防破坏 | Yes (except windows) |
| 常规 | |
|---|---|
| 保修 | Camera: 3 years / Sensor: 10 years |
| 尺寸（长 x 宽 x 高） | 378 × 96.9 × 85.4 mm (14.9 × 3.8 × 3.4 in) |
| 探测器类型 | Long-life, uncooled, sun-safe VOx microbolometer |
| 有效分辨率 | •VGA: 327,680 pixels •QVGA: 81,920 pixels |
| 输入电压 | •PoE+ (802.3at), heater off: 6.8 W •PoE+ (802.3at), heater on (@ 100%): 13.5 W •12 VDC, heater off: 7.2 W •12 VDC, heater on (@ 100%): 12.4 W •24 VAC (VA), heater off: 7.0 W •24 VAC (VA), heater on (@ 100%): 12.5 W |
| 部件编号 | 427-2064-20-00 |
| 重量 | 2.34 kg |
| 测量与分析 | |
|---|---|
| 分析技术特性 | Region entrance/Intrusion detection, Crossover/fence trespassing, CNN classifier |
| 分析技术管理 | Web-based configuration and management; masking of analytic detection areas, adjustable sensitivity, automatic responses, remote I/O control |
| 系统集成 | |
|---|---|
| 以太网 | 10/100/1000 IEEE 802.3, auto sensing 1 × RJ45 |
| 兼容外部分析软件 | Yes |
| 控制输入/输出 | 1 × dry contact in; 1 × relay out (rated load: 0.025 A @ 5 VDC) |
| 支持的协议 | IPv4, HTTP, HTTPS, UPnP, DNS,NTP, RTSP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, ONVIF Profile G/T/S |
| 网络API | NEXUS SDK, NEXUS CGI, ONVIF Profile S, G, T |
| 视频流分辨率 | •VGA: 640 × 512 •QVGA: 320 × 256 |
| 音频 | 1 × Line Input, G.711 a-law/μ-law, AAC support + 1 × Line Output |
| 热像仪 | |
|---|---|
| 像素间距 | 12 μm |
| 光圈数 | f/1.0 |
| 图像一致性优化 | Automatic flat field correction (FFC); thermal and temporal triggers |
| 波长范围 | 8 μm to 14μm |
| 灵敏度 | •VGA: <20 mK •QVGA: <30 mK |
| 热图像设置 | Brightness, Contrast, Sharpness, Auto AGC, Digital Detail Enhancement (DDE), Gamma, Smart Screen Optimization |
| 热帧频 | •VGA: 30 Hz •QVGA: 8.3 Hz |
| 热成像AGC侦测区域[ROI] | Default, Presets, and User definable to ensure optimal image quality on subjects of interest |
| 焦距 | 4.3 mm |
| 视场角（FOV） | 50° × 40° |
| 调焦 | Athermalized, focus-free |
| 阵列格式 | •VGA: 640 × 512 •QVGA: 320 × 256 |
| 视频和录制 | |
|---|---|
| IP视频 | Two independent H.265/H.264/MJPEG streams |
| 本地存储 | Up to 2TB SD card (sold separately) |
