Discontinued
FLIR SC6100
MWIR Science-Grade Camera
The versatile FLIR SC6000 Series cameras give you high speed and high resolution imagery in a package that’s easy to use yet flexible in configurations for just about any scientific or research application.
规格
| Highlighted | |
|---|---|
| 分辨率 | 640 x 512 |
| 探测器像素间距 | 25 µm |
| 波长范围 | 3.0 - 5.0 µm or 1.5 - 5.0 µm |
| 探测器类型 | Indium Antimonide (InSb) |
| 热像仪光圈数 | NA |
| 动态范围 | 14-bit |
| 热灵敏度（NETD） | <20 mK (18 mK typical) |
| 帧频[全窗口] | Programmable 0.0015 Hz to 126 Hz |
| 最大帧频[最小窗口] | 35.112 kHz (64 x 4) |
| 积分时间 | 10 µsec to 687 sec |
| 标准测温范围 | -20°C to 350°C |
| 可选测温范围 | Up to 1,500°C Up to 2,000°C |
| 成像与光学 | |
|---|---|
| 分辨率 | 640 x 512 |
| 动态范围 | 14-bit |
| 可选镜头 | NA |
| 图像时戳 | Internal IRIG-B Decoder Clock / TSPI Accurate Time Stamp |
| 子窗口模式 | User-Defined |
| 帧频[全窗口] | Programmable 0.0015 Hz to 126 Hz |
| 探测器像素间距 | 25 µm |
| 探测器类型 | Indium Antimonide (InSb) |
| 数字数据流 | Simultaneous Gigabit Ethernet and Camera Link |
| 最大帧频[最小窗口] | 35.112 kHz (64 x 4) |
| 波长范围 | 3.0 - 5.0 µm or 1.5 - 5.0 µm |
| 热像仪光圈数 | NA |
| 热灵敏度（NETD） | <20 mK (18 mK typical) |
| 积分时间 | 10 µsec to 687 sec |
| 高清视频 | NA |
| 测量与分析 | |
|---|---|
| 可选测温范围 | Up to 1,500°C Up to 2,000°C |
| 标准测温范围 | -20°C to 350°C |
| 精度 | ±1°C or ±1% of reading valid for 0°C to 3000°C on standard lens & filter configurations only |
| 通讯与数据存储 | |
|---|---|
| 同步模式 | Genlock; IRIG-B; Sync In, Sync Out |
| 模拟视频 | NTSC, PAL, S-Video, SVGA |
| 环境与认证 | |
|---|---|
| 工作温度范围 | -20°C to 50° C (-4°F to 122°F) |
Export Restrictions
The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
