红外镜头,f=5 毫米 (80°),T300805

80 度 FOV 镜头

FLIR 80 度镜头可提供卓越的宽广视野,让您能够在狭小的空间内检查大型目标。此镜头兼容 FLIR Exx、T5xx、T8xx、Axxx 系列智能传感器、Axxx 系列图像串流和 A500f/A700f 高级智能传感器热像仪。
如果将此镜头添加到现有的 FLIR 热像仪中,则需要将相机运送至附近的 FLIR 服务中心进行校准。

规格

成像与光学
光圈数 1.3, 80°
最小焦距 0.1 米
焦距 5 毫米
空间分辨率(IFOV) 取决于热像仪的红外分辨率:320 × 240 像素:5.2mrad/像素 464 × 348 像素:3.6 mrad/像素 640 × 480 像素:2.6 mrad/像素
视场角(FOV) 80° × 63°
镜头识别 自动
