PT-Series AI SR

Visible 4K and Thermal Pan/Tilt Short Range Security Camera

Product view 1
Product view 2
Product view 3
Product view 4
Product view 5

The Flir PT-Series AI SR is our most advanced multi-sensor security camera, featuring a high-performance <25 mK NETD uncooled thermal sensor with 640 × 512 resolution, a 4K visible-light imaging sensor with 25× optical zoom and outstanding low-light performance. This pan-tilt camera is enhanced with Flir Fusion AI Video analytics for reliable edge-based detection and classification of human and vehicle targets at extended ranges. Combined with Flir Nexus®, the PT-Series AI SR allows you to seamlessly track objects or people and provides uninterrupted target tracking—even beyond a radar’s field of view.
Thanks to its easy integration with United VMS and other major third party video management systems, PT-Series AI SR is an extremely versatile solution for critical infrastructure protection in total darkness, bright sun, and adverse conditions.

专为复杂应用而设计

PT系列AI SR是港口、石油和天然气设施、电力公司、商业园区或数据中心的理想选择，具有360°方位俯仰云台功能、高达1000米的可见性，以及多光谱成像，可在任何天气或照明条件下进行持续监控。

视频分析和集成

United VMS 是集成和控制 Flir PT 系列 AI SR 的强大方式。UVMS 直观易用，可根据您的需求进行扩展，支持分析、PTZ 跟踪和从固定相机到 PT 相机的切换。

了解详情

网络安全和 NDAA 合规

我们非常注重您的数据安全，正如您注重现场安全一样。Flir 安防热像仪是构建网络强化型安全系统的理想选择，尤其适用于关键基础设施和政府应用场景。Flir 将网络安全考虑因素纳入开发流程，进行内部和外部漏洞测试、严格的代码审核并采用严格的 IT 协议，确保满足《国防授权法》(NDAA) 合规标准。

了解详情

连接安全传感器与 Flir Nexus

通过 Flir Nexus 实现跨广域的无缝地理跟踪目标，Flir Nexus 是一种专有通信协议，有助于弥合 PT 系列 AI SR、其他相机、雷达设备及其监控系统之间的差距。Nexus 能够与 Flir 雷达和其他热成像和可见光相机进行无缝协调，以保持连续跟踪，即使在雷达视场之外也是如此。
Key Features
The Flir PT-Series AI-SR combines a high-sensitivity <25 mK uncooled thermal sensor with up to 4× continuous zoom and a 4K visible-light camera featuring 25× optical zoom and superior low-light performance. This powerful dual-sensor design ensures clear, actionable imaging in complete darkness, bright sunlight, and challenging weather.
Equipped with Flir Fusion AI video analytics, the PT-Series AI-SR delivers real-time object detection, classification of people and vehicles, right at the edge. This reduces false alarms, improves situational awareness, and enables faster, more accurate responses without relying on external processing.
High speed, precision pan/tilt system with 0.2° pointing accuracy ensures the PT-Series AI SR can easily maintain continuous person and vehicle tracking over wide areas.
Product showcase image
“多亏了Flir安防相机，我们现在可以在完全黑暗中以及在雾霾条件下监控围栏旁边发生的事情。如果我们看到人们接近并怀疑非法活动，我们会派出巡逻队。
Freddie Groenewald, Security Chief Technician at Namdeb, Oranjemund

规格

Compliance & Certifications
Compliance and Certifications FCC; CE Marked; RoHS; IP66; ONVIF Profile S, G, T, WEEE
Cyber Security
Security ISO27001 certified
IEEE 802.1x
TLS/HTTPS
User Authentication Access control via firewall
User credentials with policy enforcement
Digest Authentication
Environmental
De-Icing/Anti-Icing MIL-STD-810F, Method 521.1; De-Icing
Humidity 0 to 95% relative
IP Rating (dust & water ingress) IP66
Operating Temperature Range -40°C to 70°C (-40°158°F) cold start
Shock MIL-STD-810F “Transportation”
Storage Temperature Range -55°C to 85°C (-67°F to 185°F)
Vibration IEC 60068-2-27
General
Dimensions (L x W x H) 348× 467 × 326 mm (13.7, 18.4, 12.8 in)
Effective Resolution 327,680 pixels (640 × 512)
Focus Range Athermalized, Focus Free
Input Voltage 24 V DC: 65 W (max w / o heaters) 195 W (max w heaters)
Weight ~37 lb (16.8 kg): configuration dependent
Zoom Visual: 25x optical zoom
Measurement & Analysis
Programmable Presets 256
Thermal Sensitivity <25 mK at 25°C, F/10
PTZ
Pan Angle/Speed Continuous 360°; 0.1° to 60°/ sec
Tilt Angle - Speed 90° to -90°; 0.1° to 30°/ sec
System Integration
Ethernet Yes
External Analytics Compatible Yes
Network APIs Automatic Flat Field Correction (FFC) - Thermal and Temporal Triggers
Supported Protocols IPv4, HTTP, HTTPS, UPnP, DNS,NTP, RTSP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X
Thermal Camera
Array Format (Thermal) 640 × 512, long-life, uncooled VOx microbolometer
f-number F1.6 to F4.8
Focal Length 6.5 mm (wide) to 162.5 mm (tele)
Image Uniformity Optimization Automatic Flat Field Correction (FFC) - Thermal and Temporal Triggers
Lens Field of View 59.0° (wide) to 2.36° (tele)
Spectral Range (Thermal) 7.5 μm to 13.5 μm
Thermal AGC Region of Interest [ROI] Default, Presets, and User definable to ensure optimal image quality on subjects of interest
Visible Camera
f-number F1.6 to F4.8
Focal Length 6.5 mm (wide) to 162.5 mm (tele)
Lens Field of View 59.0° (wide) to 2.36° (tele)
Low Light Sensitivity Color: 0.28 lx (F1.6, AGC on, 1/30s)
Sensor Illumination Back Light Compensation
Sensor type - Daylight 4K (2160p), 1/1.8-type STARVIS II CMOS
WDR 120 dB
Video & Recording
Video Compression Two independent channels of H.265, H.264 & M-JPEG for each sensor

附件

  1. Adapter Plate (4119468)
  1. PT-Series Large Pole Adapter (500-1116-00)
  2. F-Series Small Pole Adapter (500-1121-00)
  1. PT-Series Pedestal Mount (500-1117-00)
  1. PT-Series Corner Mount (500-1118-00)
