Extech DCP60-220
Telescoping AC Current Detector
The Extech DCP60 is a highly efficient Telescoping AC Current Detector. It incorporates upgraded SMPS circuitry with small form factor, benefits from an automatic cross-over for CC and CV, has three voltage/current presets, and can be remote controlled. The DCP60 is perfect for solving a variety of loading conditions and applications. DC power supplies are used to simulate, power, and test circuits, instruments, solenoids, relays, and motors. The variable DC voltages and currents (0 V to 60 V and 0 A to 30 A) conveniently permit the user to match the supply's output to a specific application. For example, if an integrated circuit requires 5 volts or 9 volts power, the supply can be configured to output the necessary signal with high precision. Complete with power cords.
Spécifications
| Spécifications générales | |
|---|---|
| Courant de sortie | 1 to 10A |
| Ondulation et bruit | ≤5m Vrms, ≤100m Vp-p |
| Précision de base de la tension de sortie | ±(0.2% of reading + 3 digits) |
| Précision de base du courant de sortie | ±(0.2% of reading + 3 digits) |
| Régulation de la tension de charge | 50mV |
| Régulation de la tension de ligne | 20mV |
| Régulation du courant de charge | 100mA |
| Régulation du courant de ligne | 50mA |
| Tension de sortie | 1 to 60V |
| Détails supplémentaires | |
|---|---|
| Certifications | CE |
| Dimensions | 7.9 × 3.5 × 8.5" (200 × 90 × 215mm) |
| Garantie | 2 years |
| Poids | 5.7lbs (2.6kgs) |
