New
Flir i34
App-Enabled Thermal Camera
Top application
- Asset Reliability
- Building Diagnostics & Indoor Air Quality
- Electrical Inspection
- Mechanical Inspection
$6,899.00
The Flir i34 is the smart, scalable way to bring thermography to more people across your team—without compromising on consistency or control. With 240 × 320 thermal resolution and the power of the Flir ACE platform, the i34 transforms inspections into app-guided, repeatable workflows that anyone can follow—helping you capture the right data, in the right place, at the right time.
The i34 supports fully guided inspection routes, on-camera fault detection, baseline image comparison, and direct integration with Flir Assetlink and Ignite. Whether you're expanding your predictive maintenance program or reducing reliance on paper-based reporting, the i34 helps standardize inspections and eliminate guesswork—no matter the user’s experience level.
With a wide field of view, glove-friendly controls, and cybersecure data transfer behind your IT firewall, the i34 is your entry point to smarter, more connected thermography—designed to scale with your goals, not your workload.
With the advantage of Flir, 3rd-party, and custom apps, iXX-Series cameras simplify inspections and improve workflow for increased productivity. Apps can reduce the steps between data gathering and consumption, letting you work the way that makes the most sense for your organization.
On-board apps can flatten the learning curve, provide safety information, host training, and offer remote support so inexperienced users can perform expert-level inspections.
Flir iXX cameras can host a range of apps—Flir-made, 3rd-party, and custom—designed to address communication, documentation or decision-making needs.
Spécifications
| Highlighted | |
|---|---|
| Résolution IR | 240 × 320 |
| Sensibilité thermique/NETD | <40 mK at 30°C (86°F) |
| Précision | ±2°C (±3.6°F) or ±2% |
| Champ de vision (CdV) | 38° × 49° |
| Caméra numérique | 8 MP, Autofocus |
| Modes d’imagerie | MSX®, Thermal, Picture-in-Picture, Digital camera |
| Dispositif de stockage | Internal memory, onboard Flir Ignite cloud and Assetlink connectivity |
| Données image et optiques | |
|---|---|
| Alignement laser | Position of laser pointer automatically displayed on the infrared image |
| Caméra numérique | 8 MP, Autofocus |
| CdV de la caméra numérique | 50.5° × 64.5° |
| Champ de vision (CdV) | 38° × 49° |
| Couleur | Black |
| Distance minimale de mise au point | 0.5 m |
| Fréquence d'image | 30 Hz |
| Gamme spectrale | 7.5 to 13 µm |
| Mise au point | Fixed focus |
| Modes d’imagerie | MSX®, Thermal, Picture-in-Picture, Digital camera |
| Ouverture f | 1.4 |
| Palettes de couleurs | Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC |
| Réglage automatique de l’image | Yes |
| Réglage manuel de l'image | Yes |
| Résolution d'affichage | 720 × 1280 |
| Résolution IR | 240 × 320 |
| Résolution spatiale (CdV instantané) | 2.9 mrad |
| Sensibilité thermique/NETD | <40 mK at 30°C (86°F) |
| Type d’écran | 5 in. color LCD |
| Mesure et analyse | |
|---|---|
| Correction liée à l’émissivité | Variable from 0.1 to 1.0 |
| Corrections de mesure | Emissivity, matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation |
| Delta T | Yes, NFPA 70B compliant |
| Dimensions de la caméra (L × P × H) | 225 × 136 × 73 mm (8.9 × 5.4 × 2.9 in) |
| Isotherme | Above, Below |
| Plage de températures de l’objet | -20°C to 200°C (-4°F to 392°F) 10°C to 450°C (50°F to 842°F) |
| Poids de la caméra, avec batterie | 0.8 kg (1.76 lb) |
| Point de mesure | Center spot, box with min./max. |
| Précision | ±2°C (±3.6°F) or ±2% |
| Interface utilisateur | |
|---|---|
| Texte | Text annotation on image using onscreen keyboard |
| Écran tactile | Capacitive touch |
| Communication et stockage des données | |
|---|---|
| Alimentation CA | Optional accessory: 45 W AC adapter, 100 V to 240 V AC input, 15 V DC, 3 A output to camera |
| Dispositif de stockage | Internal memory, onboard Flir Ignite cloud and Assetlink connectivity |
| Formats de fichier | Standard JPEG, 14-bit measurement data included |
| Interface | USB-C: Data transfer to and from PC and Mac device Display port over USB-C |
| Wifi | IEEE 802.11 a/ac/b/g/n (2.4 and 5 GHz) |
| Alimentation | |
|---|---|
| Autonomie de la batterie | 4 hours at 25°C (77°F) ambient temperature and typical use |
| Gestion de l’alimentation | Automatic shut-down |
| Système de charge | Battery is charged inside the camera or in specific charger (included) |
| Temps de charge | 2 hours in charger / 4 hours to 90% capacity in camera |
| Type de batterie | Rechargeable Lithium-ion battery |
| Spécifications environnementales et certifications | |
|---|---|
| CEM | EN 301 489-1, EN 301 489-17, EN 61000-6-3, EN 61000-6-2, FCC 47 CFR Part 15 Class B |
| Classification laser | Class 2 |
| Humidité | IEC 60068-2-30/24 h 95% relative humidity |
| Plage de températures de fonctionnement | -15°C to 50°C (5°F to 122°F) |
| Plage de températures de stockage | -40°C to 70°C (-40°F to 158°F) |
| Résistance aux chocs | 25 g (IEC 60068-2-27) |
| Résistance aux chutes | 2 m (6ft 7 in) |
| Spectre radioélectrique | ETSI EN 300 328 ETSI EN 301 893 FCC 47 CFR part 15 RSS-247 |
| Table d'émissivité | Emissivity table of predefined materials |
| Vibration | 2 g (IEC 60068-2-6) |
| Étanchéité | IP54 (IEC 60529) |
| Informations générales | |
|---|---|
| Contenu de l’emballage | Infrared camera with battery Extra battery Battery charger USB-C cable Printed documentation Hard transport case Wrist strap |
| Lampe de travail | Manually activated bright LED |
