Extech 382202
18V/3A Single Output DC Power Supply
The Extech 382202 is a DC Power Supply which provides an adjustable 0 V to 30 V and 0 A to 1 A output. It features a dual backlit LCD display for current and voltage as well as short circuit and overload protection. Operates from 120 VAC ± 10%/60 Hz power source. Banana plug outputs. Complete with power cord.
Specifiche
| Specifiche generali | |
|---|---|
| Accuratezza di base corrente in uscita | ±2% of reading |
| Accuratezza di base tensione in uscita | ±1.5% of reading |
| Corrente in uscita | 0 – 3.00A DC |
| Regolazione corrente di carico | <0.2% + 3mA |
| Regolazione corrente di linea | <0.2% + 3mA |
| Regolazione tensione di carico | <0.01% + 2mV |
| Regolazione tensione di linea | <0.01% + 3mV |
| Ripple e rumore | <0.5mV/<3mA |
| Tensione uscita | 18.0V DC |
| Ulteriori dettagli | |
|---|---|
| Alimentazione | 115V/230V; 50/60Hz |
| Dimensioni | 9.4 × 4.25 × 6" (240 × 108 × 154mm) |
| Garanzia | 2 years |
| Peso | 6.6lbs. (3kg) |
Resources & Support
User Manual
Extech 382200 382202 User Manual
Certification
Extech 382202 Declaration of Conformity
Datasheet
Extech 382200-382202 Datasheet
Export Restrictions
The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
