Extech DCP60-220
Telescoping AC Current Detector
The Extech DCP60 is a highly efficient Telescoping AC Current Detector. It incorporates upgraded SMPS circuitry with small form factor, benefits from an automatic cross-over for CC and CV, has three voltage/current presets, and can be remote controlled. The DCP60 is perfect for solving a variety of loading conditions and applications. DC power supplies are used to simulate, power, and test circuits, instruments, solenoids, relays, and motors. The variable DC voltages and currents (0 V to 60 V and 0 A to 30 A) conveniently permit the user to match the supply's output to a specific application. For example, if an integrated circuit requires 5 volts or 9 volts power, the supply can be configured to output the necessary signal with high precision. Complete with power cords.
Specifiche
| Specifiche generali | |
|---|---|
| Accuratezza di base corrente in uscita | ±(0.2% of reading + 3 digits) |
| Accuratezza di base tensione in uscita | ±(0.2% of reading + 3 digits) |
| Corrente in uscita | 1 to 10A |
| Regolazione corrente di carico | 100mA |
| Regolazione corrente di linea | 50mA |
| Regolazione tensione di carico | 50mV |
| Regolazione tensione di linea | 20mV |
| Ripple e rumore | ≤5m Vrms, ≤100m Vp-p |
| Tensione uscita | 1 to 60V |
| Ulteriori dettagli | |
|---|---|
| Certificazioni | CE |
| Dimensioni | 7.9 × 3.5 × 8.5" (200 × 90 × 215mm) |
| Garanzia | 2 years |
| Peso | 5.7lbs (2.6kgs) |
