Flir i65
App-Enabled Thermal Imaging Camera with LTE
Top application
- Asset Reliability
- Building Diagnostics & Indoor Air Quality
- Electrical Inspection
- Mechanical Inspection
Product Variations
The Flir i65 brings the power of NFPA 70B-compliant thermal inspections to every technician, no matter their experience level. Built on the new ACE operating system, it works just like a smartphone for thermography—powered by apps, connected to the cloud, and ready to scale across teams. With high-resolution 480 × 640 thermal imaging, an intuitive 5” touchscreen, rugged, glove-friendly design, and built-in LTE connectivity, this means technicians can securely upload thermal data, share reports, and collaborate in real time—directly from the field, without needing Wi-Fi access. With sharper detail, guided workflows, and enterprise-grade cybersecurity, the i65 helps organizations cut reporting time, boost uptime, and empower teams everywhere.
With the advantage of Flir, 3rd-party, and custom apps, iXX-Series cameras simplify inspections and improve workflow for increased productivity. Apps can reduce the steps between data gathering and consumption, letting you work the way that makes the most sense for your organization.
On-board apps can flatten the learning curve, provide safety information, host training, and offer remote support so inexperienced users can perform expert-level inspections.
Flir iXX cameras can host a range of apps designed to address documentation and decision-making. Plus, the i65 offers built-in LTE for uploading, sharing, and collaborating in real time—no Wi-Fi needed—underpinned by ISO 27001-certified practices.
Specifiche
| Highlighted | |
|---|---|
| Risoluzione IR | 480 × 640 |
| Sensibilità termica/NETD | <40 mK at 30°C (86°F) |
| Range di temperatura | -20°C to 200°C (-4°F to 392°F) 10°C to 550°C (50°F to 1022°F) |
| Accuratezza | ±2°C (±3.6°F) or ±2% |
| Campo visivo (FOV) | 38° × 49° |
| Fotocamera digitale | 8 MP, Autofocus |
| Modalità immagine | MSX®, Thermal, Picture-in-Picture, Digital camera |
| Display | 5 in. 720 × 1280 color LCD |
| Supporto di memorizzazione | Internal memory, onboard Flir Ignite cloud and Assetlink connectivity |
| Dati ottici e immagine | |
|---|---|
| Allineamento laser | Position of laser pointer automatically displayed on the infrared image |
| Banda spettrale | 7.5 to 13 µm |
| Campo visivo (FOV) | 38° × 49° |
| Colore | Black |
| Distanza minima di messa a fuoco | 0.5 m |
| Fotocamera digitale | 8 MP, Autofocus |
| FOV Fotocamera digitale | 50.5° × 64.5° |
| Frequenza immagine | 30 Hz |
| Messa a fuoco | Fixed focus |
| Modalità immagine | MSX®, Thermal, Picture-in-Picture, Digital camera |
| numero f | 1.4 |
| Regolazione automatica dell’immagine | Yes |
| Regolazione manuale dell’immagine | Yes |
| Risoluzione display | 720 × 1280 |
| Risoluzione IR | 480 × 640 |
| Risoluzione spaziale (IFOV) | 1.4 mrad |
| Sensibilità termica/NETD | <40 mK at 30°C (86°F) |
| Tavolozze colori | Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC |
| Tipo display | 5 in. color LCD |
| Misurazioni e analisi | |
|---|---|
| Accuratezza | ±2°C (±3.6°F) or ±2% |
| Correzione emissività | Variable from 0.1 to 1.0 |
| Correzioni misurazione | Emissivity, matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation |
| Delta T | Yes, NFPA 70B compliant |
| Dimensioni camera (L × P × A) | 225 × 136 × 73 mm (8.9 × 5.4 × 2.9 in) |
| Isoterme | Above, Below |
| Peso camera con batteria | 0.8 kg (1.76 lb) |
| Puntatore a spot | Center spot, box with min./max. |
| Range di temperatura | -20°C to 200°C (-4°F to 392°F) 10°C to 550°C (50°F to 1022°F) |
| Range di temperature oggetto | -20°C to 200°C (-4°F to 392°F) 10°C to 450°C (50°F to 842°F) |
| Interfaccia utente | |
|---|---|
| Display | 5 in. 720 × 1280 color LCD |
| Testo | Text annotation on image using onscreen keyboard |
| Touchscreen | Capacitive touch |
| Comunicazione e Memorizzazione dati | |
|---|---|
| Cellular | Yes |
| Formati file | Standard JPEG, 14-bit measurement data included |
| Funzionamento AC | Optional accessory: 45 W AC adapter, 100 V to 240 V AC input, 15 V DC, 3 A output to camera |
| Interfaccia | USB-C: Data transfer to and from PC and Mac device Display port over USB-C |
| Supporto di memorizzazione | Internal memory, onboard Flir Ignite cloud and Assetlink connectivity |
| Wi-Fi | IEEE 802.11 a/ac/b/g/n (2.4 and 5 GHz) |
| Alimentazione | |
|---|---|
| Autonomia della batteria | 4 hours at 25°C (77°F) ambient temperature and typical use |
| Gestione alimentazione | Automatic shut-down |
| Sistema di carica | Battery is charged inside the camera or in specific charger (included) |
| Tempo di carica | 2 hours in charger / 4 hours to 90% capacity in camera |
| Tipo batteria | Rechargeable Lithium-ion battery |
| Ambientali e Certificazioni | |
|---|---|
| Cadute | 2 m (6ft 7 in) |
| Classificazione laser | Class 2 |
| EMC | EN 301 489-1, EN 301 489-17, EN 61000-6-3, EN 61000-6-2, FCC 47 CFR Part 15 Class B |
| Impatti | 25 g (IEC 60068-2-27) |
| Protezione | IP54 (IEC 60529) |
| Range di temperature di esercizio | -15°C to 50°C (5°F to 122°F) |
| Range di temperature di stoccaggio | -40°C to 70°C (-40°F to 158°F) |
| Spettro radio | ETSI EN 300 328 ETSI EN 301 893 FCC 47 CFR part 15 RSS-247 |
| Tabella emissività | Emissivity table of predefined materials |
| Umidità | IEC 60068-2-30/24 h 95% relative humidity |
| Vibrazione | 2 g (IEC 60068-2-6) |
| Generali | |
|---|---|
| Illuminatore | Manually activated bright LED |
| La confezione comprende | Infrared camera with battery Extra battery Battery charger USB-C cable Printed documentation Hard transport case Wrist strap |
| Puntatore laser | Class 2 |
