Obiettivo IR f=5 mm (80°), T300805

Obiettivo FOV a 80 gradi

L’obiettivo FLIR a 80 gradi offre un campo visivo ampio e ineguagliabile, offrendo la possibilità di ispezionare bersagli di grandi dimensioni e in spazi ristretti. Questo obiettivo è compatibile con le termocamere FLIR Exx, T5xx, T8xx, Axxx-Series Smart Sensor, Axxx-Series Imaging Streaming e A500f /A700f Advanced Smart Sensor.
Se aggiungi questo obiettivo alla termocamera FLIR esistente, essa dovrà essere spedita al centro di assistenza FLIR più vicino per la calibrazione.

Specifiche

Dati ottici e immagine
Campo visivo (FOV) 80° × 63°
Distanza minima di messa a fuoco 0,1 m
Identificazione ottica Automatica
Lunghezza focale 5 mm
numero f 1.3, 80°
Risoluzione spaziale (IFOV) A seconda della risoluzione IR della telecamera: 320 × 240 pixel: 5,2 mrad/pixel 464 × 348 pixel: 3,6 mrad/pixel 640 × 480 pixel: 2,6 mrad/pixel
