FLIR E8-XT
宽温度范围红外热像仪
FLIR E8-XT 搭载 76,800 (320 x 240) 像素的红外探测器，具有更宽的温度范围（-20°C 至 550°C [-4°F 至 1022°F]），非常适合快速定位和诊断电气、机械和建筑问题。FLIR MSX® 图像增强技术提供出色的红外成像细节，而内置 WiFi 功能则使用户能够快速连接至 FLIR Tools® 移动应用程序，随时随地分享图像和发送报告。
规格
| Highlighted | |
|---|---|
| 红外分辨率 | 320 × 240 pixels |
| 热灵敏度/NETD | <0.05°C (0.09°F) / <50 mK |
| 精度 | ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F) |
| 视场角（FOV） | 45° × 34° |
| 图像模式 | Thermal MSX, Thermal, Picture-in-Picture, Thermal blending, Digital camera. |
| 显示屏 | 3.0 in. 320 × 240 color LCD |
| 成像与光学 | |
|---|---|
| FLIR Screen-EST 模式 | No |
| 光圈数 | 1.5 |
| 图像模式 | Thermal MSX, Thermal, Picture-in-Picture, Thermal blending, Digital camera. |
| 图像频率 | 9 Hz |
| 多波段动态成像（MSX） | IR image enhanced with visible camera detail |
| 探测器类型 | Uncooled microbolometer |
| 最小焦距 | 0.5 m (1.6 ft.) |
| 波长范围 | 7.5–13 µm |
| 热灵敏度/NETD | <0.05°C (0.09°F) / <50 mK |
| 画中画 | IR area on visual image |
| 空间分辨率（IFOV） | 2.6 mrad |
| 红外分辨率 | 320 × 240 pixels |
| 视场角（FOV） | 45° × 34° |
| 调焦 | Focus free |
| 调色板 | Black & white, iron, and rainbow |
| 颜色 | Black and gray |
| 测量与分析 | |
|---|---|
| 反射表观温度校正 | Automatic, based on input of reflected temperature |
| 测温范围 | –20°C to 550°C (-4°F to 1022°F) in two ranges |
| 点温仪 | Center spot; box with min./max. |
| 热像仪尺寸（长×宽×高） | 244 × 95 × 140 mm (9.6 × 3.7 × 5.5 in) |
| 热像仪重量（含电池） | 0.575 kg (1.27 lb.) |
| 等温线 | Above alarm, below alarm |
| 精度 | ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F) |
| 设置命令 | Local adaptation of units, language, date and time formats |
| 用户界面 | |
|---|---|
| 显示屏 | 3.0 in. 320 × 240 color LCD |
| 通讯与数据存储 | |
|---|---|
| 交流运行 | AC adapter, 90–260 VAC input, 5 VDC output to camera |
| 接口 | USB Micro: Data transfer to and from PC and Mac device |
| 文件格式 | Standard JPEG, 14-bit measurement data included |
| 电源 | |
|---|---|
| 充电时间 | 2.5 hours to 90% capacity in camera. 2 hours in charger. |
| 充电系统 | Battery is charged inside the camera or in specific charger. |
| 电源管理 | Automatic shut-down |
| 环境与认证 | |
|---|---|
| 存储温度范围 | –40°C to 70°C (–40°F to 158°F) |
| 工作温度范围 | –15°C to 50°C (+5°F to 122°F) |
| 抗振动 | 2 g (IEC 60068-2-6) |
| 抗撞击 | 25 g (IEC 60068-2-27) |
| 无线电频谱 | •Standard: 802.11 b/g/n •Frequency range: •2400–2480 MHz •5150–5260 MHz •Max. output power: 15 dBm |
| 湿度（工作及存放） | IEC 60068-2-30/24 h 95% relative humidity |
| 电磁兼容性（EMC） | •WEEE 2012/19/EC •RoHs 2011/65/EC •C-Tick •EN 61000-6-3 •EN 61000-6-2 •FCC 47 CFR Part 15 Class B |
| 认证 | UL, CSA, CE, PSE and CCC |
| 常规 | |
|---|---|
| 内容清单 | •Infrared camera •Hard transport case •Battery (inside camera) •USB cable •Power supply/charger with EU, UK, US and Australian plugs •Printed documentation |
| 包装尺寸 | 385 × 165 × 315 mm (15.2 × 6.5 × 12.4 in) |
