Discontinued

Quasar 1080p FHD Dome PTZ Camera

1080p Dome PTZ Camera

The FLIR Quasar 1080p Dome PTZ camera is designed to tackle the most challenging environments. The camera combines the latest PTZ technologies, optics, mechanics and image quality performance. It is the perfect choice for city surveillance deployments, critical infrastructure, airports, and other high-profile security applications that require wide coverage.

Best-in-class image processing and optics with guaranteed frame rates.
Observe, detect and classify objects at long distances and across wide areas in diverse lighting conditions.
Built for long-lasting indoor and outdoor operations, the camera's servo-feedback motors offer accurate pan-tilt positioning, with low power consumption
Adaptive streaming, reduced bandwidth, and extended PTZ controls using Control Center or the EZ client web interface create a superior user experience.

规格

合规性与认证
USA UL, FCC Part 15 (subpart B, class A)
国际 CE marked, EN 50130-4, EN61000-6-4 (Class A), RoHS
平均故障间隔时间[小时] 348,786
网络安全
安全性 User account with password protection and IP Filter
环境
存储温度 -20° to 70° C (-4° to 158° F)
工作温度 -45° to 50° C (-49° to 122° F)
湿度 10% ~ 90% (non-condensing)
常规
24VAC CX-PRWR-241: Nema 4x 24 VAC Power Supply in Weather Resistant Enclosure for 1 PTZ
3D降噪 On / Off
AGC控制 Auto / Manual
PoE CP-POE-60W-US: 60W USA Power Injector, CP-POE-60W-EU: 60W EU Power Injector
保修 According to FLIR RMA Policy and Process Notice document
功耗 Max 25.4W (full system running)
压缩 Multi-Stream H.264 / H.265 / MJPEG
固件升级 Flash upgrade via network (1GB Flash / 2GB RAM)
外壳防护等级 IK10 / IP66
尺寸 210 × 279 mm with sun shield (8.27 × 10.98 in.)
扫描模式 Progressive
检测位置移动 On / Off
电子稳定模块 On / Off
电源连接 PoE / Terminal Block
白天/夜间：红外截止滤光片 Auto / Manual
磁泡F制光圈 Bubble transmittance 0.9 (90%)
磁泡材料 IK10 vandal resistant polycarbonate
装置重量 2.9 Kg (6.39 lbs.)
输入电压 802.3at PoE+ 24 VAC
隐私区域 On / Off - 20 zones
测量与分析
最高分辨率 1920 × 1080 (FHD1080p)
PTZ
功率损耗恢复 Yes
回零功能 Preset / Sequence / Auto Pan / Pattern
序列-自动方位/模式 8 / 4 / 8
成比例方位与俯仰云台 On / Off (pan and tilt speed proportional to zoom ratio)
手动速度 Pan: 0.1° to 90°/s, Tilt: 0.1° to 60°/s
方位/俯仰云台行程 360° continuous /-10° to 190°
水平视角 68.7° (Wide) to 2.6° (Tele)
自动翻转 Mechanical / Off
预设值-预设精度 256 / Pan: 0.16° Tilt: 0.18°
预设速度 Pan: 5° to 400° / sec Tilt: 5° to 300°/sec
系统集成
以太网 10 / 100 Base-T auto sensing, half / full duplex (RJ45)
双向音频 Full duplex, line in/line out, G.711, G.726, AAC
报警IO 4 dry contact In / 2 relay Out
报警反应 Preset / Sequence / Auto Pan / Pattern
支持的网络浏览器 Internet Explorer 10.0+
网络协议 IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF S/G, ARP, IEEE 802.1X
配置 Remote: via web access or supported VMS
音频连接 Terminal block
热像仪
DSS 1 to 1/30 (NTSC) or 1/1.5 to 1/25 (PAL)
光学变焦 30x
图像传感器 1/2.8" CMOS
宽动态范围 On / Off
数字变焦 Up to 10x
最低照度 0.3 lux (color) / 0.01 lux (BW). Measured with DSS Off at 30 IRE.
焦距 4.3 to 129 mm
可见光相机
DSS 1 to 1/30 (NTSC) or 1/1.5 to 1/25 (PAL)
信噪比 ±50 dB
光学变焦 30x
图像传感器 1/2.8" CMOS
图像旋转 Mechanical / Off
宽动态范围 On / Off
带宽 Video: Configurable between 64 Kbps and 8 Mbps, Audio: Configurable between 16 kbps & 64 Kbps
数字变焦 Up to 10x
最低照度 0.3 lux (color) / 0.01 lux (BW). Measured with DSS Off at 30 IRE.
焦距 4.3 to 129 mm
白平衡 Auto / Indoor / Outdoor / ATW / Manual
红外成像系统（Iris）控制 Auto / Manual
背光补偿 On / Off
调焦模式 Auto / Manual
视频和录制
SD卡记录 microSDXC up to 128GB (Class 10). *Excluding countries where disallowed.
分辨率范围 Scalable from CIF to HD 1080p Analog Output | 1 - composite video output BNC
最高性能 H.264/H.265 60/50 fps @ FHD + 30/25 fps @ 720P + D1 (NTSC/PAL)
视频运动检测 On / Off - up to 4 independent zones
速率控制 CBR / VBR
