Discontinued
FLIR Spark
Night Vision Monocular
The FLIR Spark is a compact night vision monocular for enhancing awareness in minimal light conditions. A rugged composite housing and built-in IR illuminator allow Spark to capture sharp imagery in challenging weather conditions or complete darkness. Optional 3x and 5x optical zoom lenses and detachable high-power IR illuminator are available for long-range wildlife viewing.
Classic, Compact Night Vision
Rugged CORE intensifier tube and onboard IR illuminator allow continuous surveillance in tough conditions.
Head, helmet, and weapon mounting options allow simple handsfree operation.
Detachable optical magnification lenses and XLR IR illuminator boost long-range performance.
规格
| Highlighted | |
|---|---|
| 工作温度 | -40°C to +50°C (-40°F to +122°F) |
| 传感器与光学 | |
|---|---|
| 亮光切断 | No |
| 光阴极类型 | N/A |
| 出射光瞳直径[mm] | 8 mm |
| 分辨率 | 60-70 lp/mm |
| 屈光度调节 | ±5 diopter |
| 放大率 | 1x standard (3x, 5x optional) |
| 第IIT代像管等级 | CORE |
| 红外发光器 | Yes |
| 自动亮度控制 | No |
| 良视距[mm] | 20 mm |
| 视场角 | 35° |
| 调焦范围 | 0.25 m to Infinity |
| 镜头系统 | F/1.7; 35 mm |
| 环境与认证 | |
|---|---|
| 存储温度 | -50°C to +70°C (-58°F to +158°F) |
| 工作温度 | -40°C to +50°C (-40°F to +122°F) |
| 电源 | |
|---|---|
| 电池寿命 | Up to 40 hours |
| 电源 | CR123 Lithium 3V (1) or CR123 type rechargeable batteries with voltage 3.2V (1) |
| 自动关机 | No |
| 文件存储和通讯 | |
|---|---|
| 远程控制 | - |
| UI-UX | |
|---|---|
| 十字线颜色 | - |
| 手动增益控制 | No |
| 红外指示器 | Yes (Led) |
| 系统概览 | |
|---|---|
| 保修 | 2 Years |
| 十字线类型 | - |
| 轨道之上观测装置轴线的高度 | - |
| 风阻_仰角调节 | - |
| 物理 | |
|---|---|
| 三脚架 | - |
| 产品重量 | 0.37 kg (0.8 lbs) |
| 尺寸（长 x 宽 x 高） | 181× 49 × 82 mm (7.1 × 1.9 × 3.2 in) |
| 配件 | |
|---|---|
| 可选附件 | PASGT Helmet Mount Assembly USA #108 with Adapter/Swing Arm #37, Swing Arm #172, MICH Helmet Mount Assembly USA #107 with Adapter/Swing Arm #37, XLR-IR Afocal Doubler - Doubles the distance of XLR-IR850 IR beam, XLR-IR850 Detachable X-Long Range Infrared Illuminator w/Dovetail to Weaver Transfer Piece #21, AIM PRO - Advanced Integrated Mount Pro, ARFS3 - Advanced Range Finding Stadia for 3x Afocal Lens, Helmet Mount #170 (Shroud), 5x Afocal Lens with Adapter #23, 3x Afocal Lens Kit: Lens #22 with Adapter #23, ARFS5 - Advanced Range Finding Stadia for 5x Afocal Lens, AIM Pro-L - Advanced Integrated Mount Pro, Goggle Kit #1, Mil-Standard Hard Shipping/Storage Case #101, Swing Arm #37, Helmet Mount #3, Universal Camera Adapter #45, QRM - Quick Release Picatinny Mount Adapter #26/#142, Extended Rail Adapter #85 |
| 随附配件 | Soft carrying Case, One Lithium Battery CR123A, Packing Box, Lens Tissue, Instruction Manual with Warranty Card |
附件
资源和支持
Datasheet
Spark Datasheet
Warranty
FLIR Outdoor And Tactical Systems Limited 2-3-10 Warranty
Brochure
Teledyne FLIR Thermal Monoculars for Public Safety Brochure
