USS Edge Appliance
Compact IP Video Appliance with Built-in PoE
The FLIR USS Edge Appliance is a compact video appliance ideal for small to medium-sized security deployments. It comes equipped with an eight-port Power over Ethernet (PoE) switch and can hold from 2 TB up to 20 TB of video storage. The built-in installer simplifies setup for the FLIR UVMS* (Video Management Software) and reduces installation time. The USS Edge Appliance is an enterprise-grade solution that can be used as an independent VMS or to extend security systems across multiple locations.
*Video Management software is sold separately, please visit https://www.flir.com/browse/security/video-management-systems/ to explore the available options.
• Reduce installation time with easy-to-use installation interface
• Small form factor reduces power consumption and environmental footprint
• Reduce the need for 8-point PoE switch
• Simple design allows technicians to quickly install and perform routine maintenance
• Easy-to-use interface helps solve problems faster
• Protected by a three-year warranty
• CE, FCC, LVD, and UL (optional) - Certified
规格
| 合规性与认证 | |
|---|---|
| 认证 | CE/FCC/LVD (Standard, UL will be charged additionally) |
| 环境 | |
|---|---|
| 工作温度 | 0°C to 40°C (32°F to 104°F) |
| 常规 | |
|---|---|
| PoE | 8 × 10/100 RJ45 ports |
| 保修 | 3 years |
| 内存 | USS-EDGE-G5-02TB, USS-EDGE-G5-04TB: 16 GB DDR5 USS-EDGE-G5-08TB, USS-EDGE-G5-12TB, USS-EDGE-G5-16TB, USS-EDGE-G5-20TB: 32 GB DDR5 |
| 功耗 | 80 W min, 200 W max, POE Power 120 W |
| 处理器 | USS-EDGE-G5-02TB, USS-EDGE-G5-04TB: Alder Lake I3-12100E USS-EDGE-G5-08TB, USS-EDGE-G5-12TB, USS-EDGE-G5-16TB, USS-EDGE-G5-20TB: Alder Lake I5-12500E |
| 尺寸 | 43.9 × 220 × 244.3 mm (1.72 × 8.66 × 9.62 in) |
| 形状因数 | Small and compact Form Factor with 8-port POE switch |
| 操作系统 | Microsoft Windows 11 IoT LTSC 2024 |
| 电源 | 200 W; 100 to 240 VAC, 50/60 Hz, Single non-redundant power supply |
| 监视 | USS-EDGE-G5-02TB, USS-EDGE-G5-04TB, USS-EDGE-G5-08TB: Up to 220 FPS at 1080p USS-EDGE-G5-12TB, USS-EDGE-G5-16TB, USS-EDGE-G5-20TB: Up to 280 FPS at 1080p |
| 重量 | max. weight: 2.5 kg (5.5 lb) |
| 系统集成 | |
|---|---|
| USB端口 | USB2.0 x2; USB3.2 x2; (front) USB3.2 Type-C x1 (rear) 1x eSata |
| 联网 | Dual NIC, 2 × 10/100/1000 Mbps RJ45 |
| 音频 | Via HDMI or 3.5 mm audio jack 1 x Mic-in / 1 x Headphone-out |
| 视频和录制 | |
|---|---|
| 硬盘驱动器存储 | USS-EDGE-G5-02TB: 2 TB 3.5 in SATA USS-EDGE-G5-04TB: 4 TB 3.5 in SATA USS-EDGE-G5-08TB: 8 TB 3.5 in SATA USS-EDGE-G5-12TB: 12 TB 3.5 in SATA USS-EDGE-G5-16TB: 16 TB 3.5 in SATA USS-EDGE-G5-20TB: 20 TB 3.5 in SATA |
| 记录 | USS-EDGE-G5-02TB, USS-EDGE-G5-04TB: 80 Mbps USS-EDGE-G5-08TB, USS-EDGE-G5-12TB, USS-EDGE-G5-16TB, USS-EDGE-G5-20TB: 150 Mbps |
