Extech 392052
Flat Surface Stem Dial Thermometer
The Extech 392052 is a Flat Surface Stem Dial Thermometer with a temperature range of -50°C to 300°C ±2°C (-58°F to 572°F ±2°F). Ideal for measuring high temperatures on motors and other flat surfaces. The thermometer features a 12.7 cm (5 in) stainless steel shaft with a 5.1 cm (2 in) dial, an on/off switch, and auto power off function after one hour. Product includes 1.5 V battery button.
Specifications
| General | |
|---|---|
| Temperature | -58 to 572°F(-50 to 300°C) |
| Temperature Basic Accuracy | ±1.8°F (1°C) from –22 to 452°F (-30 to 250°C) : ±4°F(2°C) outside this range |
| Temperature Max Resolution | 0.1°C/F to 199.9°C/F, 1°C/F > 199.9°C/F |
| Additional Details | |
|---|---|
| Certifications | CE |
| Dimensions | 5" (130mm) stainless steel probe with 0.57”(14.5mm) tip and 2" (54mm) dial |
| Display | 2000-count segment LCD |
| Power | 1 × 1.5V button battery |
| Warranty | 2 years |
| Weight | 1oz (29g); 1.3oz (30g) with protective sheath |
Resources & Support
User Manual
Extech 392052 User Manual
Datasheet
Extech 392050 392052 Datasheet
Certification
Extech 392052 Declaration of Conformity
