适用于 Axxx 系列的 IP67 外壳 (T912366)

适用于 FLIR A400/A500/A700 型号的保护外壳

Product view 1
Product view 2
Product view 3
Product view 4

这款符合 IP67 等级的铝制保护外壳专为 Flir Axxx 系列设计。由于采用了 Flir 专有的辐射测量算法，保护外壳内相机的精度保持在标准规范内。兼容的配件包括冷却块/护套、遮阳罩和多种安装选配件。

注意：锗窗口会阻挡可见光相机。

The window, upgraded

A better window. The same part number.

The IP67 housings now ship with a chalcogenide-glass IR window—equivalent optics, the same hardened coating, and a supply chain you can schedule around.

Equivalent optics, verified

88–90% transmission across the 7–14 µm band, with radiometric accuracy unchanged. Confirmed in testing against the germanium reference window.

Stable as temperatures climb

A low thermo-optic coefficient keeps optical properties consistent—the same material class automotive thermal cameras qualify from -40°C to 85°C (-40°F to 185°F).

Hardened like before

The same AR + DLC diamond-like-carbon coating as the previous window, meeting MIL-spec abrasion, humidity, and salt-spray standards.

Supply you can plan on

Moves the window off constrained germanium supply—protecting availability and the delivery dates behind your camera order.


Beat the Heat

One housing platform. Ambient operation to 90°C.

Start with the housing alone, then add cooling jackets and blocks as conditions demand—the same camera keeps working as ambient climbs.

Extended Operation with Cooling

Ambient temperature  →  housing configuration (IP67 aluminum)

-20°C to 50°C (-4°F to 122°F) Housing as-is No cooling accessories required
50°C to 55°C (122°F to 131°F) 1 cooling jacket Jacket fitted on one side
55°C to 60°C (131°F to 140°F) 1 jacket + air Air-fed jacket on one side
60°C to 70°C (140°F to 158°F) 2 jackets + air Air-fed jackets, both sides
70°C to 90°C (158°F to 194°F) 4 blocks + air Air-fed cooling on every side



附件

  1. 适用于 Axxx IP67 外壳的 Air Knife [T912381]
  2. 适用于 Axxx 系列的 IP67 外壳，带有热成像和可见光观察窗 (T912659)
  3. 适用于 T912366 的 Axxx IP67 冷却夹套
  4. Axxx 系列冷却块

资源和支持

Datasheet

FLIR Axx IP67/IP69k 外壳数据表

下载

Export Restrictions

The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
