Extech DCP60-220
Telescoping AC Current Detector
The Extech DCP60 is a highly efficient Telescoping AC Current Detector. It incorporates upgraded SMPS circuitry with small form factor, benefits from an automatic cross-over for CC and CV, has three voltage/current presets, and can be remote controlled. The DCP60 is perfect for solving a variety of loading conditions and applications. DC power supplies are used to simulate, power, and test circuits, instruments, solenoids, relays, and motors. The variable DC voltages and currents (0 V to 60 V and 0 A to 30 A) conveniently permit the user to match the supply's output to a specific application. For example, if an integrated circuit requires 5 volts or 9 volts power, the supply can be configured to output the necessary signal with high precision. Complete with power cords.
Especificaciones
| Especificaciones generales | |
|---|---|
| Corriente de salida | 1 to 10A |
| Fluctuación y ruido | ≤5m Vrms, ≤100m Vp-p |
| Precisión básica de corriente de salida | ±(0.2% of reading + 3 digits) |
| Precisión básica de voltaje de salida | ±(0.2% of reading + 3 digits) |
| Regulación de corriente de carga | 100mA |
| Regulación de corriente de línea | 50mA |
| Regulación de voltaje de carga | 50mV |
| Regulación de voltaje de línea | 20mV |
| Voltaje de salida | 1 to 60V |
| Detalles adicionales | |
|---|---|
| Certificaciones | CE |
| Dimensiones | 7.9 × 3.5 × 8.5" (200 × 90 × 215mm) |
| Garantía | 2 years |
| Peso | 5.7lbs (2.6kgs) |
