FCB-Series AI
Thermal AI Analytics Camera
Product Variations
The FCB-Series AI thermal security camera turns noisy, cluttered sites into clear, dependable views your team can act on. With industry-leading thermal sensitivity (<20 mK), it visualizes objects through fog, drizzle, and night-time glare, so a person slipping between stacked containers or walking along a dark campus fence line doesn’t vanish in the shadows. Onboard AI analytics distinguish people and vehicles from swaying trees or rain on the lens, cutting the nuisance alarms that currently flood your VMS. Nexus-enabled geolocation and PTZ handoff let operators click on a target and follow it around corners, along the fence, or between buildings, while flexible lens options and an IP67 housing make it easy to cover awkward yard layouts, loading bays, and remote installations.
This is a camera built for real sites, not lab conditions
Flir Nexus의 장점
FCB 시리즈 AI, 다른 보안 카메라, 레이더 장치 및 모니터링 시스템 간의 격차 해소를 지원하는 특허 받은 통신 프로토콜인 Flir Nexus를 통해 넓은 영역 전반에서 대상물을 원활하게 지오트래킹(geo-track)할 수 있습니다. Nexus는 원활한 연동 기능을 제공하여 단일 기기의 시야 범위를 넘어 지속적인 추적을 유지할 수 있습니다.
사이버 보안 및 국방수권법(NDAA) 준수
사용자가 사이트 보안을 중요하게 여기는 만큼 당사는 사용자의 데이터 보안을 중요하게 생각합니다. FCB 시리즈 AI 카메라는 주요 기반시설 및 정부 애플리케이션을 위한 사이버 강화 보안 시스템에 이상적입니다. Flir 개발 제품은 내부 및 외부 취약성 테스트, 엄격한 코드 검토, 철저한 IT 프로토콜 등과 함께 당사 프로세스에 사이버 보안 고려사항을 통합하여 NDAA(미국 국방수권법) 준수 기준을 충족합니다.
• Deep-learning analytics are trained to lock onto human and vehicle movement.
• Fewer false alarms from waving foliage or rain.
• Security teams see alarms when someone climbs the fence, instead of wasting time clearing endless false alerts.
• Fewer false alarms from waving foliage or rain.
• Security teams see alarms when someone climbs the fence, instead of wasting time clearing endless false alerts.
• Industry-leading thermal sensitivity (<20 mK) reveals subtle temperature differences that standard thermal and visible cameras miss.
• Crisp thermal silhouettes visible between parked vehicles, misty yards, or across campus boundaries.
• Operators can detect and respond with confidence.
• Crisp thermal silhouettes visible between parked vehicles, misty yards, or across campus boundaries.
• Operators can detect and respond with confidence.
• Five lens options (18° to 50° FOV) and a wide viewing capability let you cover long fence lines, tight corners around warehouses, and irregular building layouts without leaving blind spots.
• Nexus-enabled geolocation and PTZ handoff mean an intruder spotted at a remote gate can be instantly handed over to a PTZ for close-up tracking.
• Rugged IP67 camera built to endure dust, heat, and driving rain at remote energy sites and busy industrial yards.
• Nexus-enabled geolocation and PTZ handoff mean an intruder spotted at a remote gate can be instantly handed over to a PTZ for close-up tracking.
• Rugged IP67 camera built to endure dust, heat, and driving rain at remote energy sites and busy industrial yards.
사양
| Analytics | |
|---|---|
| Cybersecurity | Password protection, Password policy enforcement, IP filtering, IEEE 802.1X, Digest authentication, CA & self-signed certificates, Firewall |
| Compliance & Certifications | |
|---|---|
| Compliance | CB Scheme IEC 62368-1:2018, comply with IEC62368-1:2020+A112020 |
| Environmental | |
|---|---|
| De-Icing\Defogging | •De-fog: Yes, built in heaters •De-icing: No |
| EMC | CE marked (EN 55032 & EN 55035) , EN 61000-6-3, EN 50130-4, FCC Part 15 (subpart B, class A), RoHS, WEEE, UKCA, ICES-003, AS/NSZ CISPR 32 |
| Handling Shock | ISTA 3A |
| Humidity | 0-95% relative humidity |
| IP Rating (dust & water ingress) | IP67, NEMA 4X |
| Operating Temperature Range | -40°C to 60°C/-40°F to 140°F (cold start) |
| Storage Temperature Range | -50°C to 85°C (-58°F to 185°F) |
| Vandal Resistance | Yes (except windows) |
| General | |
|---|---|
| Detector Type | Long-life, uncooled, sun-safe VOx microbolometer |
| Dimensions (L x W x H) | 378 × 96.9 × 85.4 mm (14.9 × 3.8 × 3.4 in) |
| Effective Resolution | •VGA: 327,680 pixels •QVGA: 81,920 pixels |
| Input Voltage | •PoE+ (802.3at), heater off: 6.8 W •PoE+ (802.3at), heater on (@ 100%): 13.5 W •12 VDC, heater off: 7.2 W •12 VDC, heater on (@ 100%): 12.4 W •24 VAC (VA), heater off: 7.0 W •24 VAC (VA), heater on (@ 100%): 12.5 W |
| Part Number | 427-2064-20-00 |
| Warranty | Camera: 3 years / Sensor: 10 years |
| Weight | 2.34 kg |
| Measurement & Analysis | |
|---|---|
| Analytics Features | Region entrance/Intrusion detection, Crossover/fence trespassing, CNN classifier |
| Analytics Management | Web-based configuration and management; masking of analytic detection areas, adjustable sensitivity, automatic responses, remote I/O control |
| System Integration | |
|---|---|
| Audio | 1 × Line Input, G.711 a-law/μ-law, AAC support + 1 × Line Output |
| Control Input/Output | 1 × dry contact in; 1 × relay out (rated load: 0.025 A @ 5 VDC) |
| Ethernet | 10/100/1000 IEEE 802.3, auto sensing 1 × RJ45 |
| External Analytics Compatible | Yes |
| Network APIs | NEXUS SDK, NEXUS CGI, ONVIF Profile S, G, T |
| Streaming Resolution | •VGA: 640 × 512 •QVGA: 320 × 256 |
| Supported Protocols | IPv4, HTTP, HTTPS, UPnP, DNS,NTP, RTSP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, ONVIF Profile G/T/S |
| Thermal Camera | |
|---|---|
| Array format | •VGA: 640 × 512 •QVGA: 320 × 256 |
| f-number | f/1.0 |
| Field of view (FOV) | 50° × 40° |
| Focal Length | 4.3 mm |
| Focus | Athermalized, focus-free |
| Image Uniformity Optimization | Automatic flat field correction (FFC); thermal and temporal triggers |
| Pixel Pitch | 12 μm |
| Sensitivity | •VGA: <20 mK •QVGA: <30 mK |
| Spectral Range | 8 μm to 14μm |
| Thermal AGC Region of Interest [ROI] | Default, Presets, and User definable to ensure optimal image quality on subjects of interest |
| Thermal Frame Rate | •VGA: 30 Hz •QVGA: 8.3 Hz |
| Thermal Image Settings | Brightness, Contrast, Sharpness, Auto AGC, Digital Detail Enhancement (DDE), Gamma, Smart Screen Optimization |
| Video & Recording | |
|---|---|
| IP Video | Two independent H.265/H.264/MJPEG streams |
| Local Storage | Up to 2TB SD card (sold separately) |
액세서리
Resources & Support
Export Restrictions
이 페이지에 포함된 정보는 최종 제품의 사양에 따라 국제 무기 거래 규정(ITAR)(22 C.F.R. 섹션 120-130) 또는 수출 관리 규정(EAR)(15 C.F.R. 섹션 730-774)의 적용을 받을 수 있는 제품에 관한 것입니다. 요청 시 관할권과 분류를 제공합니다.
