Discontinued
FLIR X6980™
MWIR-Hochgeschwindigkeitskameras für wissenschaftliche Zwecke
Product Variations
Die FLIR X6980 ist eine außergewöhnlich schnelle IR-Mittelwellenkamera, die für Wissenschaftler und Ingenieure entwickelt wurde, die für genaue thermische Analysen und individuelle radiometrische Messungen Hochgeschwindigkeitsbilder aufnehmen müssen. Diese Wärmebildkamera kombiniert eine Auflösung von 640 × 512 mit blitzschnellen Bildraten, sodass Forscher sich schnell bewegende Objekte oder schnelle Temperaturänderungen—im Labor oder im Testbereich mit Stop-Motion aufzeichnen können. Mit einem motorgetriebenen Filterrad mit vier Positionen und Unterstützung für motorgetriebene Fokusobjektive von FLIR ermöglicht die X6980 bessere Aufnahmen, spart Zeit und verringert die Frustration in dynamischen Aufnahmeumgebungen.
Aufnahme scharf fokussierter Wärmebilder mit voller Auflösung von 640 × 512 bei bis zu 1004 Hz bei sehr geringem Rauschen
Speichern Sie bis zu 26.000 Frames an Daten direkt in den Speicher auf der Kamera oder bis zu 15 Minuten mit einer 512 GB SSD
Streamen Sie thermische Daten direkt auf einen Computer, um sie mit FLIR Research Studio anzusehen, aufzuzeichnen und zu analysieren
Specifications
| Highlighted | |
|---|---|
| Resolution | 640 × 512 |
| Detector Pitch | 25 µm |
| Spectral Range | X6980 InSb, X6982 InSb: 1.5–5.0 µm X6981 InSb, X6983 InSb: 3.0–5.0 µm |
| Detector Type | FLIR indium antimonide (InSb) |
| Camera f_number | X6980 InSb, X6981 InSb: f/2.5 X6982 InSb, X6983 InSb: f/4.1 |
| Dynamic Range | 14-bit |
| NETD | 20 mK typical |
| Frame Rate [Full Window] | Programmable: 0.0015 Hz to 1004 Hz |
| Integration Time | Programmable: 270 ns to ~full frame |
| Standard Temperature Range [with band matched optics] | X6980 InSb, X6982 InSb: -20°C to 350°C (-4°F to 662°F) X6981 InSb, X6983 InSb: -20°C to 350°C (-4°F to 662°F), -10°C/14°F for microscopes |
| Optional Temperature Range [with band matched optics] | ND1: 45°C–600°C (113°F–1112°F) ND2: 250°C–2000°C (482°F–3632°F) ND3: 500°C–3000°C (932°F–5432°F) |
| Filtering | 4-Position motorized warm filter wheel, standard 1-inch filters, user swappable |
| Focus | Motorized (compatible w/manual) |
| Bildgebung und optische Daten | |
|---|---|
| Available Lenses | X6980 InSb, X6982 InSb: Manual (broadband): 25 mm, 50 mm, 100 mm
Motorized (broadband): None X6981 InSb, X6983 InSb: Manual (3–5 µm): 17 mm, 25 mm, 50 mm, 100 mm, 200 mm Motorized (3–5 µm): 17 mm, 25 mm, 50 mm, 100 mm, 200 mm |
| Camera f_number | X6980 InSb, X6981 InSb: f/2.5 X6982 InSb, X6983 InSb: f/4.1 |
| Close_up Lenses_Microscopes | X6980 InSb, X6982 InSb: No broadband microscopes available X6981 InSb: 1x, 3x, 50mm close focus X6983 InSb: 1x, 3x, 1x20 cm long working distance (LWD), 50 mm close focus |
| Detector Pitch | 25 µm |
| Detector Type | FLIR indium antimonide (InSb) |
| Digital Zoom | 1x, Auto (best fit) |
| Direct to SSD Recording | Yes, removable 512 GB SSD included |
| Download of On_Camera RAM, SSD Recordings | Transfer from SSD through GigE, CXP, or CL to Research Studio v2.1 or higher |
| Dynamic Range | 14-bit |
| Filtering | 4-Position motorized warm filter wheel, standard 1-inch filters, user swappable |
| Focus | Motorized (compatible w/manual) |
| Frame Rate [Full Window] | Programmable: 0.0015 Hz to 1004 Hz |
| Image Time Stamp | Internal IRIG-B decoder clock TSPI accurate time stamp |
| Integration Time | Programmable: 270 ns to ~full frame |
| Lens Interface | FLIR FPO-M (4-tab bayonet, motorized) |
| NETD | 20 mK typical |
| On Camera Image Storage | RAM (volatile): 16 GB, up to 26,000 frames full frame SSD (user-removable/non-volatile): ~15 minutes of ~800 Hz recording with included 512 GB SSD (more than 2 hours possible with 4 TB SSD purchased separately) |
| Operability | >99.95% typical |
| Overlay | Customizable (Ability to toggle off) |
| Palette | Selectable 8-bit |
| Pixel Clock | 355 MHz |
| Radiometric Data Streaming | Simultaneous Gigabit Ethernet (GigE Vision), Camera Link,CoaXPress® 1.1, dual 5 Gb links |
| Readout Modes | Asynchronous integrate while read, Asynchronous integrate then read |
| Readout Type | Snapshot |
| Resolution | 640 × 512 |
| Sensor Cooling | Closed cycle rotary |
| Spectral Range | X6980 InSb, X6982 InSb: 1.5–5.0 µm X6981 InSb, X6983 InSb: 3.0–5.0 µm |
| Standard Video | HDMI, SDI |
| Subwindow Modes | Flexible windowing down to 32 × 4 (steps of 32 columns, 4 rows) |
| Video Modes | HD-SDI: 720p@50/59.9Hz, 1080p@25/29.97Hz; SD-SDI: 480i@60Hz, 576i@50Hz |
| Messung und Analyse | |
|---|---|
| Accuracy | ≤100°C: ±2°C (±1°C typical), >100°C: ±2% of reading (±1% typical) |
| Ambient Drift Compensation [with factory cal] | Yes |
| Automatic Gain Control | Manual, Linear, Plateau equalization, ROI, DDE |
| Optional Temperature Range [with band matched optics] | ND1: 45°C–600°C (113°F–1112°F) ND2: 250°C–2000°C (482°F–3632°F) ND3: 500°C–3000°C (932°F–5432°F) |
| Standard Temperature Range [with band matched optics] | X6980 InSb, X6982 InSb: -20°C to 350°C (-4°F to 662°F) X6981 InSb, X6983 InSb: -20°C to 350°C (-4°F to 662°F), -10°C/14°F for microscopes |
| Kommunikation und Datenspeicher | |
|---|---|
| Synchronization Modes | Sync In, Sync Out, Tri-Level Sync |
| Stromversorgung | |
|---|---|
| Power | 24 VDC (<50 W steady state) |
| Umgebungsfaktoren und Zertifizierungen | |
|---|---|
| Mounting | 2 × 1/4 in. -20 / 1 × 3/8 in. -16 / 4 × #10 -24 / Side: 3x 1/4 in. -20 (each side) |
| Operating Temperature Range | -20°C to 50°C (-4°F to 122°F) |
Accessories
- FLIR Cooled Science A-Series + X-Series Camera Power Connector (26399-000)
- 1x Microscope Protective Window - MWIR & LWIR (4206654-6)
- FLIR X-Camera Filter Wheel Holders
- FLIR Cooled Science X-Series + A-Series Camera Universal Lens Support (4210086)
- FPO Bayonet Plug, 4-Tab FPO Bayonet (4142249)
- Extender Ring Set, 4 Rings 0.25", 0.50", 0.75", & 1.00", 4-Tab FPO Bayonet (4205079)
- FLIR X-Camera Filter Wheel Removal Wrench (C1004.M202)
- 3x Microscope Protective Window - MWIR ONLY (4219929)
