i65
App-Enabled Thermal Imaging Camera with LTE
Top application
- 자산 신뢰성
- 건물 진단 및 실내 공기 품질
- 전기 검사
- 기계 검사
The Flir i65 brings the power of NFPA 70B-compliant thermal inspections to every technician, no matter their experience level. Built on the new ACE operating system, it works just like a smartphone for thermography—powered by apps, connected to the cloud, and ready to scale across teams. With high-resolution 480 × 640 thermal imaging, an intuitive 5” touchscreen, rugged, glove-friendly design, and built-in LTE connectivity, this means technicians can securely upload thermal data, share reports, and collaborate in real time—directly from the field, without needing Wi-Fi access. With sharper detail, guided workflows, and enterprise-grade cybersecurity, the i65 helps organizations cut reporting time, boost uptime, and empower teams everywhere.
Mit den Vorteilen von Flir-, Drittanbieter- und benutzerdefinierten Apps vereinfachen die Kameras der iXX-Serie Inspektionen und verbessern den Workflow für eine höhere Produktivität. Apps können die Schritte zwischen Datenerfassung und -verbrauch reduzieren, sodass Sie so arbeiten können, wie es für Ihr Unternehmen am sinnvollsten ist.
On-board apps can flatten the learning curve, provide safety information, host training, and offer remote support so inexperienced users can perform expert-level inspections.
Flir iXX-Kameras können eine Reihe von Apps hosten, die auf Dokumentation und Entscheidungsfindung ausgerichtet sind. Darüber hinaus bietet der i65 integriertes LTE zum Hochladen, Teilen und Zusammenarbeiten in Echtzeit – ohne WLAN –, unterstützt durch ISO 27001-zertifizierte Praktiken.
사양
| 강조 표시됨 | |
|---|---|
| IR-Auflösung | 480 × 640 |
| Thermische Empfindlichkeit / NETD | <40 mK at 30°C (86°F) |
| Temperaturbereich | -20°C to 200°C (-4°F to 392°F) 10°C to 550°C (50°F to 1022°F) |
| Genauigkeit | ±2°C (±3.6°F) or ±2% |
| Sichtfeld (FOV) | 38° × 49° |
| Digitalkamera | 8 MP, Autofocus |
| Bildmodi | MSX®, Thermal, Picture-in-Picture, Digital camera |
| Display | 5 in. 720 × 1280 color LCD |
| Speichermedien | Internal memory, onboard Flir Ignite cloud and Assetlink connectivity |
| Bildgebung und optische Daten | |
|---|---|
| Automatische Bildeinstellung | Yes |
| Bildfrequenz | 30 Hz |
| Bildmodi | MSX®, Thermal, Picture-in-Picture, Digital camera |
| Blendenzahl | 1.4 |
| Digitalkamera | 8 MP, Autofocus |
| Display-Auflösung | 720 × 1280 |
| Display-Typ | 5 in. color LCD |
| Farbe | Black |
| Farbpaletten | Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC |
| Fokus | Fixed focus |
| IR-Auflösung | 480 × 640 |
| Laserausrichtung | Position of laser pointer automatically displayed on the infrared image |
| Manuelle Bildeinstellung | Yes |
| Mindestfokusabstand | 0.5 m |
| Räumliche Auflösung (IFOV) | 1.4 mrad |
| Sichtfeld (FOV) | 38° × 49° |
| Sichtfeld Digitalkamera | 50.5° × 64.5° |
| Spektralbereich | 7.5 to 13 µm |
| Thermische Empfindlichkeit / NETD | <40 mK at 30°C (86°F) |
| Messung und Analyse | |
|---|---|
| Delta T | Yes, NFPA 70B compliant |
| Emissionsgrad-Korrektur | Variable from 0.1 to 1.0 |
| Genauigkeit | ±2°C (±3.6°F) or ±2% |
| Isotherm | Above, Below |
| Kameragewicht mit Akku | 0.8 kg (1.76 lb) |
| Kameramaße (L × B × H) | 225 × 136 × 73 mm (8.9 × 5.4 × 2.9 in) |
| Messpunkt | Center spot, box with min./max. |
| Messwertkorrekturen | Emissivity, matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation |
| Objekttemperaturbereich | -20°C to 200°C (-4°F to 392°F) 10°C to 450°C (50°F to 842°F) |
| Temperaturbereich | -20°C to 200°C (-4°F to 392°F) 10°C to 550°C (50°F to 1022°F) |
| Benutzeroberfläche | |
|---|---|
| Display | 5 in. 720 × 1280 color LCD |
| Text | Text annotation on image using onscreen keyboard |
| Touchscreen | Capacitive touch |
| Kommunikation und Datenspeicher | |
|---|---|
| Cellular | Yes |
| Dateiformate | Standard JPEG, 14-bit measurement data included |
| Schnittstelle | USB-C: Data transfer to and from PC and Mac device Display port over USB-C |
| Speichermedien | Internal memory, onboard Flir Ignite cloud and Assetlink connectivity |
| Wechselstrombetrieb | Optional accessory: 45 W AC adapter, 100 V to 240 V AC input, 15 V DC, 3 A output to camera |
| WLAN | IEEE 802.11 a/ac/b/g/n (2.4 and 5 GHz) |
| Stromversorgung | |
|---|---|
| Akkubetriebsdauer | 4 hours at 25°C (77°F) ambient temperature and typical use |
| Akkutyp | Rechargeable Lithium-ion battery |
| Energiemanagement | Automatic shut-down |
| Ladedauer | 2 hours in charger / 4 hours to 90% capacity in camera |
| Ladesystem | Battery is charged inside the camera or in specific charger (included) |
| Umgebungsfaktoren und Zertifizierungen | |
|---|---|
| Betriebstemperaturbereich | -15°C to 50°C (5°F to 122°F) |
| Emissionsgrad-Tabelle | Emissivity table of predefined materials |
| EMV | EN 301 489-1, EN 301 489-17, EN 61000-6-3, EN 61000-6-2, FCC 47 CFR Part 15 Class B |
| Funkwellenspektrum | ETSI EN 300 328 ETSI EN 301 893 FCC 47 CFR part 15 RSS-247 |
| Gehäuse | IP54 (IEC 60529) |
| Lagertemperaturbereich | -40°C to 70°C (-40°F to 158°F) |
| Laserklassifizierung | Class 2 |
| Luftfeuchtigkeit | IEC 60068-2-30/24 h 95% relative humidity |
| Stoßfestigkeit | 25 g (IEC 60068-2-27) |
| Sturzfestigkeit | 2 m (6ft 7 in) |
| Vibrationen | 2 g (IEC 60068-2-6) |
| Allgemeine Angaben | |
|---|---|
| Arbeitsleuchte | Manually activated bright LED |
| Laserpointer | Class 2 |
| Lieferumfang | Infrared camera with battery Extra battery Battery charger USB-C cable Printed documentation Hard transport case Wrist strap |
