Acyclica RoadTrend
Data Collection
The RoadTrend is the premier workhorse for congestion data collection! Designed to optimize the collection process, the RoadTrend can collect over 250,000 records per hour, providing a new benchmark in performance. The compact data collection device needs only power, communication and a 2.4 GHz antenna.
사양
| System Overview | |
|---|---|
| Data Capture Rate | Up to 250,000 records per hour |
| Data Interface | NTCIP Center-to-Center XML |
| Data Latency | 35 seconds |
| Data Storage Capacity | 100 MB (internal) / 32GB (USB storage) |
| Communications | |
|---|---|
| Connectivity | 10/100BaseT |
| WiFi | 1 Watt 2.4Ghz Radio |
| Electrical | |
|---|---|
| CPU | 1 GHz Cortex ARM7 |
| MTBF | > 100,000 hours |
| Power Consumption | < 5 Watts |
| Power Requirements | 5VDC |
| Environmental | |
|---|---|
| Relative Humidity | 10% to 90% non-condensing |
| Temperature Range | -20° to 75° C (industrial option: -40° to 85° C) |
Export Restrictions
The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
