Discontinued
IR850-XLR Detachable LED Extra Long Range Infrared Illuminator
Night vision devices rely on small amounts of ambient light to capture clear imagery. FLIR’s Extra Long Range Infrared Illuminator uses near IR light invisible to the naked eye to covertly illuminate subjects in complete darkness, allowing night vision optics to produce a better image. The powerful IR850-XLR model offers beam angle adjustment and variable power control. Included rechargeable battery can operate up to 10 hours while an optional Afocal Doubler increases long-range performance.
Technische Daten
| Sensor und optische Daten | |
|---|---|
| Divergenzwinkel | 4° to 35° |
| Spitzenwert der Wellenlänge | 850 nm |
| Umgebungsfaktoren und Zulassungen | |
|---|---|
| Umgebungsbedingungen | Water and fog Resistant |
| Stromversorgung | |
|---|---|
| Batterielaufzeit bei 20 °C [68 °F] | up to 10 hours (1/4 Power), up to 8 hours (1/2 Power), up to 6 hours (3/4 Power), up to 2.5 hour (Full Power) |
| Netzteil | One 18650 (3.7v ) Rechargeable Battery |
| Stromversorgung | 1000 mW |
| Systemübersicht | |
|---|---|
| IR-Emitter-Typ | LED |
| Kompatible Nachtsichtgeräte | Gen 1, CORE, Gen2, Gen 3, Digital |
| Physikalische Daten | |
|---|---|
| Abmessungen [ohne Montagehalterung] | 150 x 46 x 46 mm (5.9 x 1.8 x 1.8 in) |
| Gewicht | 0.21 kg (0.46 ibs), without mount and battery |
Resources & Support
Datasheet
IR850-XLR Datasheet
