Extech MA435T
400A True RMS AC/DC Clamp Meter + NCV
The Extech MA435T is a compact, 400 A AC Clamp Meter that enables users to take measurements in tight spaces. The 30 mm (1.2 in) jaw opening can accommodate conductors up to 350 MCM. Featuring a large, four digit readout, the illuminated display is easy to see in poorly lit work areas, and the thumb dial selector is ergonomically placed for convenient, one-hand operation. It also has True RMS for better accuracy when measuring distorted waveforms. The MA435T’s multimeter functions include AC/DC voltage and current, resistance, capacitance, frequency, diode test, duty cycle, continuity, and thermocouple temperature. Also built into the MA435T is the non contact voltage (NCV) detector. Eliminating the need for a separate tester, the NCV detector uses a red LED to alert users to the presence of voltage on live wires. Additional features include data hold, auto power off, and low battery indication. Comes with test leads, 9 V battery, soft carrying case, and user manual.
Technische Daten
| Allgemeine technische Daten | |
|---|---|
| Berührungsloser Spannungsprüfer (NCV) | Yes |
| Diodentest | Yes |
| Durchgang | Yes |
| Echteffektivwert (TRMS) | Yes |
| Frequenz | 10Hz to 10kHz |
| Frequenz Grundgenauigkeit | ±(1.5% of reading + 2 digits) |
| Gleichspannung | 600V |
| Gleichspannung Grundgenauigkeit | ±(1.5% of reading + 2 digits) |
| Gleichspannung Max. Auflösung | 0.1mV |
| Gleichstrom Grundgenauigkeit | ±(2.5% of reading + 5 digits) |
| Gleichstrom Max. Auflösung | 0.01A |
| Gleichstromstärke | 400A |
| Kapazität | 100µF |
| Kapazität Max. Auflösung | 0.01nF |
| Temperatur (Typ K) Max. Auflösung | -4 to 1400 °F/-20 to 760 °C |
| Temperatur (Typ N) | ±(3% of reading + 9°F/5°C) |
| Temperatur (Typ N) Grundgenauigkeit | 0.1°F/°C |
| Wechselspannung | 600V |
| Wechselspannung Grundgenauigkeit | ±(1.5% of reading + 5 digits) |
| Wechselspannung Max. Auflösung | 0.1mV |
| Wechselstrom | 400A |
| Wechselstrom Grundgenauigkeit | ±(2.5% of reading + 8 digits) |
| Wechselstrom Max. Auflösung | 0.01A |
| Widerstand | 40MΩ |
| Widerstand Max. Auflösung | 0.1Ω |
| Zangenöffnung | 1.2" (30mm), conductors up to 350MCM |
| Weitere Details | |
|---|---|
| Abmessungen | 7.8 × 2.8 × 1.6" (197 × 70 × 40mm) |
| Display | 4000-count segment LCD |
| Garantie | 2 years |
| Gewicht | 6.5oz (183g) |
| Sicherheitskategorie | CATIII - 600V |
| Stromversorgung | 1 × 9V battery |
| Zertifizierungen | CE, ETL |
