Extech MA150
200A Mini AC Clamp Meter + NCV Detector
The Extech MA150 Mini Clamp Meter offers the convenience of a built in non contact AC voltage detector and bright white LED flashlight. It measures AC current up to 200 A with 0.1 A resolution while also measuring AC/DC voltage and resistance. The 1.8 cm (0.7 in) jaw fits around conductors up to 300 MCM. Its compact size allows getting into tight spaces. The MA150 features an auto power off function, data hold, and low battery indicator. Includes two AAA batteries and case.
Specifications
| General | |
|---|---|
| AC Current | 200A |
| AC Current Basic Accuracy | ±2.5% |
| AC Current Max Resolution | 100mA |
| AC Voltage | 600V |
| AC Voltage Max Resolution | 0.1mV |
| DC Voltage | 600V |
| DC Voltage Max Resolution | 0.1mV |
| Jaw Size | 0.7" (18mm) |
| Non_Contact Voltage [NCV] Detector | Yes |
| Resistance | 20MΩ |
| Resistance Max Resolution | 0.1Ω |
| Additional Details | |
|---|---|
| Certifications | CE |
| Dimensions | 7 × 2.5 × 1.3" (178 × 65 × 32mm) |
| Power | 2 × AAA (1.5V) batteries |
| Safety Category | CATII - 600V, CATIII - 300V |
| Warranty | 2 years |
| Weight | 6 oz (170g) |
Resources & Support
Certification
Extech MA150 Declaration of Conformity
User Manual
Extech MA150 User Manual
Datasheet
Extech MA120 MA150 Datasheet
Export Restrictions
The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
