Extech 382202
18V/3Aシングル出力DC電源
Extech 382202は、0V～30Vおよび0A～1Aの出力を調整可能なDC電源です。電流および電圧用のデュアルバックライトLCDディスプレイ、短絡および過負荷保護を備えています。AC120V ±10%/60Hz電源で動作します。バナナプラグ出力。電源コードが付属しています。
仕様
| 一般仕様 | |
|---|---|
| Line Current Regulation | <0.2% + 3mA |
| Line Voltage Regulation | <0.01% + 3mV |
| Load Current Regulation | <0.2% + 3mA |
| Load Voltage Regulation | <0.01% + 2mV |
| Output Current | 0 – 3.00A DC |
| Output Current Basic Accuracy | ±読み取り値の2% |
| Output Voltage | 18.0V DC |
| Output Voltage Basic Accuracy | ±読み取り値の1.5% |
| Ripple and Noise | <0.5mV/<3mA |
| 追加の詳細 | |
|---|---|
| Dimensions | 240×108×154mm |
| Power | 115V/230V; 50/60Hz |
| Warranty | 2年 |
| Weight | 3kg |
