USS Client Workstation
クライアントワークステーション
FLIR USS Clientは、セキュリティオペレーションセンターが基本的なものであれ先進のものであれ、 そのニーズに応えるように設計された高性能で効率の良いワークステーションであり、 FLIRのビデオ管理システム製品のために最適化されています。
仕様
| 適合性と認定 | |
|---|---|
| Certifications | Nemko, CE, FCC, C-Tick, ICES, VCCI, CCC, KC |
| 一般仕様 | |
|---|---|
| Dimensions | H × W × D : 290 × 93 × 292 mm (11.42 × 3.65 × 11.5 in) |
| Form Factor | Small form factor |
| Memory | 16 GB (2 × 8 GB) DDR5 4800 MHz |
| Monitoring | USS Client Workstation, Dual Monitor: Up to 400 fps 1080p USS Client Workstation, Quad Monitor: Up to 500 fps 1080p USS Client Workstation, Quad Monitor - High Performance: Up to 600 fps 1080p |
| Operating System | Microsoft® Windows 10 Professional (x64) |
| Optical Drive | 8x DVD±RW 9.5 mm Slimline optical disk drive |
| Peripherals | QuietKey USB keyboard and optical scroll USB mouse |
| Power Supply | 300 W up to 92% efficient (80 Plus Platinum) PSU (System Fan), 100~240 VAC 50/60 Hz (auto) |
| Processor | USS Client Workstation, Dual Monitor: Enterprise Quad-core Intel® Core i3-10105 USS Client Workstation, Quad Monitor: Intel® Core i5-12500 processor 3.0 GHz to 4.6 GHz USS Client Workstation, Quad Monitor - High Performance: Intel® Core i7-12700 processor, 12 Core (8P+4E), 2.1 GHz to 4.9 GHz, 65 W |
| Warranty | 3-year ProSupport and Next Business Day On-site Service (upgrades available) |
| Weight | 5.26 kg (11.57 lb) |
| システム統合 | |
|---|---|
| Audio Controller | Via HDMI or 3.5 mm audio jack 1 x Mic-in / 1 x Headphone-out |
| Communication | Integrated Gigabit Ethernet controller |
| Display Ports | USS Client Workstation, Dual Monitor: 2 display ports USS Client Workstation, Quad Monitor, USS Client Workstation, Quad Monitor - High Performance: 2x display ports, 3x mini display ports |
| I_O Ports | RJ45, USB 2.0 port, USB 2.0 port PowerShare, USB 3.2 Gen 2 port, USB 3.2 Gen 2×2 capable Type-C® port, Universal audio port, Serial/PS2 port SD 4.0 card slot (optional) |
| I_O Slots | SD 4.0 card slot (optional), half-height Gen 4 PCIe x16 slot, half-height Gen 3 PCIe x4 slot ,M.2 2230 slot for Wi-Fi and Bluetooth® card, M.2 2280 slot for solid-state drive (2), M.2 2230/2280 for solid-state drive (3), SATA 3.0 slot for 3.5/2.5-inch hard drive |
| Networking | Dual NIC, 2x 10/100/1000 Mbps RJ-45 |
| 動画と録画 | |
|---|---|
| Hard Drive | M.2 256 GB PCIe NVMe Class 35 Solid State Drive |
