FLIR CO-LR-LRF
108 mm Night Vision Clip-On System
Designed for long-range target detection and engagement, the FLIR CO-LR-LRF adds high-performance night vision to any standard day scope. Using an existing ballistic reticle for shot placement, the CO-LR-LRF provides immediate precision by quickly mounting in front of day optics—no rezeroing needed. Variable gain control and included XLR IR illuminator further enhance imaging in challenging light conditions.
사양
| 센서 및 광학 기기 | |
|---|---|
| IIT 생성 | Gen 2+ QS ("Quick Silver" White Phosphor) MG |
| 광음극 유형 | Multi-Alkali |
| 눈동자 거리 [mm] | - |
| 디옵터 조정 | - |
| 렌즈 시스템 | F/1.54; 108 mm |
| 배율 | 1× (recommended to use with up to 12x day time optics) |
| 섬광_차단 | Yes |
| 시야각 (FOV) | 9° |
| 자동 밝기 제어 | Yes |
| 적외선 조명기 | Detachable Long Range IR |
| 초점 범위 | 25 m to Infinity |
| 출사동 직경 [mm] | 50 mm |
| 해상도 | 47-54 lp/mm |
| 환경 및 승인 | |
|---|---|
| 보관 온도 | -50°C to +70°С (-58°F to +158°F) |
| 작동 온도 | -40°C to +50°С (-40°F to +122°F) |
| 전원 | |
|---|---|
| 배터리 사용 시간 | Up to 45 hours |
| 배터리 잔량 부족 표시등 | Yes (in FOV) |
| 자동 전원 차단 | Yes |
| 전원공급장치 | CR123 Lithium 3V (1) or AA Alkaline 1.5V (1) or any AA or CR123 type rechargeable batteries with voltage from 1.2V to 3.7V (1) |
| 파일 저장 및 통신 | |
|---|---|
| 원격 조정 | Wireless |
| UI-UX | |
|---|---|
| 레티클 색상 | - |
| 수동 게인 (Gain) 제어 | Yes |
| 적외선 표시등 | No |
| 시스템 개요 | |
|---|---|
| 레일 위 스코프 축 높이 | 40 mm |
| 레티클 유형 | - |
| 보증 | 2 Years |
| 편류_엘리베이션 조정 | - |
| 물리적 특성 | |
|---|---|
| 삼각대 마운트 | - |
| 제품 무게 | 1.1 kg (2.4 lbs) |
| 크기(L x W x H) | 240 х 97 х 87 mm (9.4 х 3.8 х 3.4 in) |
| 액세서리 | |
|---|---|
| 옵션형 액세서리 | Extended Rail Adapter #85, FSRS (Front Scope Rail System) #38, Mil-Standard Hard Shipping/Storage Case #102, XLR-IR Afocal Doubler - Doubles the distance of XLR-IR850 IR beam, AMRF2200 - Advanced Modular Range Finder |
| 포함 액세서리 | Battery adapter CR123A 3V / AA 1.5V, XLR-IR850 Detachable X-Long Range Infrared Illuminator, Adjustment-Control-DeviceBattery, Picatinny adapter for AWReC (Advanced Wireless Remote Control), AWReC (Advanced Wireless Remote Control) #94, Instruction Manual with Warranty Card, Special Wrench, Light-Suppressor, Soft carrying Case, Packing Box, Lens Tissue |
액세서리
리소스 및 지원
Datasheet
CO-LR-LRF Datasheet
Warranty
FLIR Outdoor And Tactical Systems Limited 2-3-10 Warranty
Brochure
Teledyne FLIR Thermal Monoculars for Public Safety Brochure
Export Restrictions
The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
