Discontinued
FLIR CO-XLR-LRF
145 mm Night Vision Clip-On System
The FLIR CO-XLR-LRF is the most advanced night vision clip-on in its family. High-performance image intensifier tubes and extra long-range 145 mm optical lens generate superior imagery for engaging targets at extended distances. Installed in front of a standard day optic, the CO-XLR-LRF offers immediate high-quality night vision and precise shot placement—no rezeroing needed. Included XRL IR illuminator maintains excellent image quality in adverse lighting conditions.
Elite Long-Range Performance
145 mm lens and Gen 3 intensifier tubes generate outstanding long-range night vision and quickly detect targets downrange.
Front-mounting allows consistent ballistic reticle use and maintains familiar shot position, release, and follow-through.
Quick-release Picatinny mounting ensures proper rail position and installs in seconds—no tools required.
Especificaciones
| Sensor y óptica | |
|---|---|
| Ajuste de dioptría | - |
| Alivio ocular (mm) | - |
| Aumento | 1x (recommended to use with up to 16x day time optics) |
| Campo de visión | 7° |
| Control de brillo automático | Yes |
| Corte_de luz brillante | Yes |
| Diámetro de pupila de salida (mm) | 50 mm |
| Generación de IIT | FLAG - Filmless Auto-Gated IIT MG |
| Iluminador de infrarrojos | Detachable Long Range IR |
| Rango de enfoque | 25 m to Infinity |
| Resolución | 64-72 lp/mm |
| Sistema de lente | F/1.8; 145 mm |
| Tipo de fotocátodo | GaAs |
| Características medioambientales y aprobaciones | |
|---|---|
| Temperatura de almacenamiento | -50°C to +70°С (-58°F to +158°F) |
| Temperatura operativa | -40°C to +50°С (-40°F to +122°F) |
| Alimentación | |
|---|---|
| Apagado automático | Yes |
| Duración de la batería | Up to 60 hours |
| Fuente de alimentación | CR123 Lithium 3V (1) or AA Alkaline 1.5V (1) or any AA or CR123 type rechargeable batteries with voltage from 1.2V to 3.7V (1) |
| Indicador de baja carga de la pila | Yes (in FOV) |
| Almacenamiento de archivos y comunicación | |
|---|---|
| Control remoto | Wireless |
| UI-UX | |
|---|---|
| Color de retícula | - |
| Control de ganancia manual | Yes |
| Indicador de IR | No |
| Descripción general del sistema | |
|---|---|
| Ajuste de la elevación_y corrección del viento | - |
| Altura del eje de óptica sobre el raíl | 40 mm |
| Garantía | 2 Years |
| Tipo de retícula | - |
| Características físicas | |
|---|---|
| Dimensiones (L × An × Al) | 304 × 104 × 94 mm (12.0 × 4.0 × 3.7 in) |
| Montaje en trípode | - |
| Peso del producto | 1.30 kg (2.86 lbs) |
| Accesorios | |
|---|---|
| Accesorios incluidos | Battery adapter CR123A 3V / AA 1.5V, XLR-IR850 Detachable X-Long Range Infrared Illuminator, Adjustment-Control-Device, Battery, Picatinny adapter for AWReC (Advanced Wireless Remote Control, AWReC (Advanced Wireless Remote Control) #94, Instruction Manual with Warranty Card, Special Wrench, Light-Suppressor, Soft carrying Case, Packing Box, Lens Tissue |
| Accesorios opcionales | Extended Rail Adapter #85, FSRS (Front Scope Rail System) #38, Mil-Standard Hard Shipping/Storage Case #102, XLR-IR Afocal Doubler - Doubles the distance of XLR-IR850 IR beam, AMRF2200 - Advanced Modular Range Finder |
