Extech MN47
12 Function Compact MultiMeter + NCV
The compact, manual ranging MN47 digital mini multimeter is equipped with the extensive capabilities for both active tradesman and hobbyist alike. In addition to its electronic and electrical testing functions, the MN47 adds value with a built in, non-contact voltage detector. You won't have to search for a voltage pen in order to safely check for voltage prior to attaching the multimeter's test leads. A bright red LED alerts you to the presence of voltage. Complete with test leads, bead wire Type K probe, 9 V battery, and a carrying case.
Especificaciones
| Especificaciones generales (Extech) | |
|---|---|
| Capacitancia | 100µF |
| Ciclo de trabajo | 0.1 to 99.9% |
| Continuidad | Yes |
| Corriente CA | 10A |
| Corriente CC | 10A |
| Detector de tensión sin contacto (VSC) | 100 to 600VAC |
| Frecuencia | 10MHz |
| Prueba de diodos | Yes |
| Resistencia | 40MΩ |
| Resolución básica de tensión CC | 0.1mV |
| Resolución máx. de capacitancia | 1pF |
| Resolución máx. de corriente CA | 0.1µA |
| Resolución máx. de corriente CC | 0.1µA |
| Resolución máx. de frecuencia | 0.001Hz |
| Resolución máx. de resistencia | 0.1Ω |
| Resolución máx. de temperatura (tipo K) | 1400 °F (760 °C) |
| Resolución máx. de tensión CA | 0.1V |
| Voltaje CA | 600V |
| Voltaje CC | 600V |
| Detalles adicionales | |
|---|---|
| Alimentación | 1 × 9V battery |
| Categoría de seguridad | CATIII - 600V |
| Certificaciones | CE |
| Dimensiones | 5.9 × 2.75 × 1.8" (150 × 70 × 48mm) |
| Garantía | 2 years |
| Pantalla | 4000-count segment LCD |
| Peso | 9oz (255g) |
Recursos y asistencia
User Manual
Manual del usuário de Extech MN47
Certification
Extech MN47 Declaration of Conformity
User Manual
Extech MN47 User Manual
Datasheet
Extech MN42-MN47 Datasheet
Export Restrictions
