• Easy, Flexible Operation

    View data on both the large backlit LCD display and from iOS® or Android™ mobile devices using the ExView app via Bluetooth.

  • Standalone Capture and Display

    Measure light intensity data up to 100,000 Lux (10,000 Fc), record max/min readings, and freeze the display with ‘data hold’ feature.

  • Portable Collection, Analysis, and Reporting

    Export .CSV data; create and send PDF reports including photos of the measurement location taken with a connected smartphone or tablet camera.

Specifications
General Specifications
Light (Foot Candle)
0 to 18,571 Fc
Light (Foot Candle) Basic Accuracy
±4% of reading (<9,999 Fc); ±5% of reading (≥10,000 Fc)
Light (Foot Candle) Max Resolution
1 Fc (<9,999 Fc); 10 Fc (≥10,000 Fc)
Light (Lux)
0 to 199,900 Lux
Light (Lux) Basic Accuracy
±4% of reading (<9,999 Lux); ±5% of reading (≥10,000 Lux)
Light (Lux) Max Resolution
1 Lux (<9,999 Lux); 10 Lux (≥10,000 Lux); 100 Lux (≥100,000 Lux)
Sampling Rate
0.5 sec
Wireless Connectivity
Bluetooth® (via ExView iOS/Android mobile app)
Wireless Transmission Range
up to 90 m line of sight
Additional Details
Certifications
CE, FCC, UKCA
Dimensions
6.9 × 2.1 × 1.1 in (176 × 53 × 28 mm)
Display
5-digit (99999-count) backlit segment LCD display
Operating Conditions
32 to 104°F (0 to 4°C),≤80% RH
Power
3 × AAA (1.5V) batteries
Warranty
2 years
Weight
3.2 oz (90 g)
