The compact, manual ranging MN47 digital mini multimeter is equipped with the extensive capabilities for both active tradesman and hobbyist alike. In addition to its electronic and electrical testing functions, the MN47 adds value with a built in, non-contact voltage detector. You won't have to search for a voltage pen in order to safely check for voltage prior to attaching the multimeter's test leads. A bright red LED alerts you to the presence of voltage. Complete with test leads, bead wire Type K probe, 9 V battery, and a carrying case.
Specifications
| General | |
|---|---|
| AC Current | 10A |
| AC Current Max Resolution | 0.1µA |
| AC Voltage | 600V |
| AC Voltage Max Resolution | 0.1V |
| Capacitance | 100µF |
| Capacitance Max Resolution | 1pF |
| Continuity | Yes |
| DC Current | 10A |
| DC Current Max Resolution | 0.1µA |
| DC Voltage | 600V |
| DC Voltage Max Resolution | 0.1mV |
| Diode Test | Yes |
| Duty Cycle | 0.1 to 99.9% |
| Frequency | 10MHz |
| Frequency Max Resolution | 0.001Hz |
| Non_Contact Voltage [NCV] Detector | 100 to 600VAC |
| Resistance | 40MΩ |
| Resistance Max Resolution | 0.1Ω |
| Temperature [Type K] Max Resolution | 1400 °F (760 °C) |
| Additional Details | |
|---|---|
| Certifications | CE |
| Dimensions | 5.9 × 2.75 × 1.8" (150 × 70 × 48mm) |
| Display | 4000-count segment LCD |
| Power | 1 × 9V battery |
| Safety Category | CATIII - 600V |
| Warranty | 2 years |
| Weight | 9oz (255g) |
Resources & Support
Datasheet
Extech MN42-MN47 Datasheet
Certification
Extech MN47 Declaration of Conformity
User Manual
Extech MN47 User Manual
Export Restrictions
The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
