AID and data collection board for IP cameras

FLIR VIP-HD

Go to Product Support
product image

The FLIR VIP-IP is a multi-functional Video Image Processing module for traffic control. VIP-IP boards process video input from D1 resolution IP cameras for automatic incident detection, data collection, recording of pre and post incident image sequences and streaming video (single H.264, MPEG-4, MJPEG). VIP-IP boards have been installed for road and tunnel projects all over the world.

  • Automatic Incident Detection

    FLIR VIP-IP alerts on a variety of events, including stopped vehicles, wrong-way drivers, queues, slow-moving vehicles, fallen objects and pedestrians.

  • Robust traffic data collection

    FLIR VIP-IP collects traffic data, detects queues and emulates loops on highways and inter-urban roads.

  • Easy to install and operate

    FLIR VIP-IP is a reliable, 24/7 detection solution that offers a long lifetime.

Specifications
General
MTBF
200,000 hrs
Overview
Boards per Rack
8 in 19" Rack
Description
AID module for full HD IP cameras
Dimensions
130 x 41 x 190 mm
Encoding Format
H.264, MPEG-4, MJPEG
Maximum Streams
Max 4 unicast or multicast
Multi-Streaming
Single H.264 or MPEG-4 or MJPEG
Power
< 4W
Analytics
AID
AID overlay
Connections & Communications
Communication Standards
SNMP
Data
No
LAN Connector Type
10/100 Mbps RJ45
PTZ control
No
Electrical & Mechanical
Stand_Alone Form
Box, 24 V DC (+/- 15%)
Weight
200 g
Environmental & Approvals
Operating Temperature
-34° to +74°C (-29° to 165°F)
Measurement & Analysis
Maximum resolution
Full HD (1920x1080) @ 30 fps
System Integration
Audio
No
Digital Inputs
1
Digital Outputs
2
Video Input
IP video: up to full HD in H264 or MPEG-4
