Specifications
Overview
- Detector Type
- Focal plane array (FPA), uncooled microbolometer
- Spectral Range
- 8–14 µm
Compliance & Certifications
- Certifications
- CE/PSE/EN/UL/CSA 60950-1
Environmental
- Drop test
- Designed for 2 m (6.6 ft.)
- Emissivity Correction
- No
- Encapsulation
- IP 40 (IEC 60529)
- Operating Temperature Range
- –10 to +45°C (+14 to 113°F)
- Storage Temperature Range
- –40 to +70°C (–40 to 158°F)
Imaging & Optical
- Camera size (L x W x H)
- 169 mm × 113 mm × 48 mm (6.6 in. × 4.4 in. × 1.9 in.)
- Camera weight incl battery
- 0.21 kg (0.46 lb.)
- Color palettes
- Iron
- Field of view (FOV)
- 55° × 43°
- Focus
- Focus free
- Image Frequency
- 9 Hz
- Minimum Focus Distance
- 0.1 m (4 in.)
Measurement & Analysis
- Center spot
- Yes
- Object Temperature Range
- –10 to +150°C (+14 to +302°F)
- Temperature Unit
- Selectable by switch; °C or °F
Meter Data
- Display
- 1.8 in. TFT LCD
Power
- Battery operating time
- 4 hours continuous scanning
- Battery type
- 3 × AAA (LR03)
- Power Management
- Fixed; 5 min.
Shipping Information
- Includes
- Imaging IR spot thermal camera, Printed documentation, Lanyard, 3 × AAA (LR03) batteries
