FLIR ThermoSight® RS24
Support Center

FLIR ThermoSight® RS24

Go to Product Details Page

For Support
Please call (+1) 603-324-7600

For Service
Call (888) 959-2259

Resources:
FLIR Outdoor & Tactical Systems 2-3-10 Limited Warranty
Download
ThermoSightR-Series Brochure
Download
Specifications
System Overview
Eye Relief
3 inches (76.2 mm)
Frame Rate [Hz]
30 Hz
Ingress Protection
IPX7, Submersible 1m for 30 min
Size (L x W x H)
8" × 3.3" × 2.9"
Warranty
2 Years Standard, 3 Years (with registration), 10 Years (thermal sensor only)
Weapon Compatibility
MSR semi-automatic up to .308 Cal.
Weapon Interface
MIL-STD-1913 Picatinny Rail
Weight
<1.8lb
Connections & Communications
Video Out
No
Environmental & Approvals
Operating Temperature
-4° to 122° F (-20° to 50° C)
Storage Temperature
-40° to 140° F (-40° to 60° C)
Imaging & Optical
Color palettes
Black/White/InstAlert™
Diopter Adjustment
+/-6
Display
Active Matrix LCD
Display resolution
640 × 480
E-Zoom
N/A
Focal Plane Array (FPA)
240 × 180 VOx
Focus
Fixed
Lens HFOV
20°
Power
Battery Charging
Standard USB interface with included wall charger
Battery life
>4 hours of use
Battery type
Internal Li-ion
External Battery Pack
Compatible, not included
Presentation
Reticle Colors
White, Black, Red, Green
User Interface
Simple four button interface
On Screen Symbology
Battery charge, E-Zoom state
Sensor Specifications
Lens Focal Length
13mm
Reticles
Duplex, Fine Duplex, German
